HD3G7 HD 3 Gb/s SDI Video Generator module

HD3G7 module factory default settings

3–212
The following table shows the factory default settings for the HD3G7 module.
These settings are recalled when you select Factory Default from the PRESET :
RECALL menu item in the mainframe main menu.
Table 3-39: HD3G7 module factory default settings
Menu item name
TEST SIGNAL
FORMAT
SAMPLE STRUCTURE/DEPTH
OUTPUT MODE
MOVING PICTURE
H Step
V Step
Period
Random
AUDIO (EMBEDDED)
Status (Level A)
Group 1–4
Status (Level B)
Group 1–4 Link A
Group 1–4 Link B
Channel
Status
Frequency
Amplitude
Audio Click
Channel Origin
Sampling
TIMING
Vertical
Horizontal
Relative To
TIMECODE
Source
30 Drop Frame
ATC-LTC
ATC-VITC
Settings
100% Color Bars
1080 59.94p
YCbCr 4:2:2 10b
3G-Level A (1920 × 1080)
0 Sample(s)
0 Line(s)
1 Frame(s)
Disable
Disable
Disable
Disable
Active
1000
–20 dBFS
OFF
A1-1 through A4-4
Frame
0 Line(s)
0.0000 μs
Serial (0H)
Program Time
Enable
OFF
OFF
