INPUT-OUTPUT. Use the left (◄) or right (►) arrow button configure the
BLACK 1 connector as an INPUT or an OUTPUT (if allowed). This connector
is forced to be an input if the TIMING REFERENCE SOURCE is set to a Genlock
signal or if VITC is the TIME OF DAY reference.
NOTE.
If a reference signal is connected to the BLACK 1 / REF IN connector, you
should configure this connector as an input so that the GPS7 module does not
output a video signal if the Reference Source is changed to GPS or internal.
This might occur when using the GPS7 module in a dual-configuration where the
module is being switched between being a slave via genlock to incoming video or
a master source using the GPS/GLONASS reference.
This menu selection is available only when BLACK 1 is selected for configuration
and the GPS7 module has the BLACK 1 / REF IN connector.
FORMAT. Use the left (◄) or right (►) arrow button to select from the signal
formats in the following table. Press the ENTER button to confirm the selection.

Table 3-21: GPS7 module output signal formats

Common
NTSC
NTSC-J
PAL
CW 10 MHz 2
1
The signal formats available in this submenu depend on the HD trilevel sync rate setting (non-integer or integer),
which is set using the Select Output selection in the GPS7 module main menu. (See page 3-113, GPS7 module
main menu.)
2
The CW 10 MHz format is available on the BLACK 3 output only.
FIELD REFERENCE. Use the left (◄) or right (►) arrow button to Enable or
Disable the field reference in the output signal. Press the ENTER button to
confirm the selection.
NOTE.
This submenu is available only when a non-HD format is set as the signal
format of the selected BLACK output.
GPS7 GPS Synchronization and Timecode module
Non-integer HD trilevel
1
sync rate
1080 59.94i
1080 23.98sf
1080 29.97p
1080 23.98p
720 59.94p
Integer HD trilevel sync
1
rate
1080 60i
1080 50i
1080 24sf
1080 30p
1080 25p
1080 24p
720 60p
720 50p
3–123
