2.3 Intercom Setup

2.3.1 Mechanical Adjustment

The SIP-enabled h.264 Video Outdoor Intercom with Keypad has a mechanical adjustment that
ships in the default position of 0 degrees horizontal
down or 15 degrees up as shown in
Camera
Operations Guide
Figure 2-3. Mechanical Adjustment at 0 degrees horizontal
931338B
Installing the SIP-enabled h.264 Video Outdoor Intercom with Keypad
(Figure 2-3), but it allows you to tilt it 15 degrees
Figure 2-4 and Figure 2-5.
0 degrees
0 degrees
Intercom Setup
Screw used for adjustment
