A.4 Network Cable Entry Restrictions
A.4.1 Rear Conduit Network Cable Entry Restrictions (without Shroud)
See
A.4.2 Rear Conduit Network Cable Entry Restrictions (with Shroud)
See
Operations Guide
Figure A-3
for the rear conduit cable entry restrictions (without Shroud).
Figure A-3. Rear Conduit Network Cable Entry Restrictions—Without Shroud
1/2" Conduit Connector
Figure A-4
for the rear conduit cable entry restrictions (with shroud).
Figure A-4. Rear Conduit Network Cable Entry Restrictions—With Shroud
Network Cable,
1/2" Conduit &
1/2" Conduit Connector
are not provided.
Add Spacer Here
Network Cable,
1/2" Conduit &
are not provided.
Add Spacer Here
931338B
Network Cable Entry Restrictions
CyberData Corporation
93
