CyberData 011490 Installation Quick Reference

Dimensions and Rear View with Mounting Holes
2.76 [70]
Dimensions are in Inches [Millimeter]
© 2021, CyberData Corporation, ALL RIGHTS RESERVED
Mounting Hole
Ø0.280 [Ø7.11]
(4 Places)
1/2" Conduit Hole
Ø0.854 [Ø21.69]
1.690 [42.93]
5.122 [130]
931658C Quick Reference
Installation Quick Reference
Outdoor Auxiliary RGB
The IP Endpoint Company
(Multi-Color) Strobe Kit
011490
Parts List
• (1) Outdoor Auxiliary RGB (Multi-Color) Strobe Kit
• (1) 3.28 feet [1 meter] cable
Features
• Meets ADA requirements for telephony signaling and notification
• Activates from a CyberData IP endpoint
• Mailbox Message Waiting Indication
• Multicast activation
Getting Started
• Download the Operations Guide PDF file, from the Downloads tab at the following
webpage:
https://www.cyberdata.net/products/011490
• Create a plan for the locations of your Outdoor Auxiliary RGB (Multi-Color) Strobe Kits.
• WARNING: This product should be installed by a licensed electrician according to all local
electrical and building codes.
• WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in
accordance with the installation instructions.
• WARNING: This enclosure is not rated for any AC voltages!
Parts
Accessory Kit
(1) Hole plug assembly
(4) Phillips Screws (4) Security Torx Screws
(1) T-15H Torx Key
Contacting CyberData
Corporate Headquarters
CyberData Corporation
Sales: 831-373-2601 ext. 334
3 Justin Court
Support: 831-373-2601 ext. 333
Monterey, CA 93940, USA
Support Website:
RMA Department Contact and Status:
Phone: 831-373-2601
Warranty Information:
Fax: 831-373-4193
http://www.cyberdata.net/
Quick Reference
Optional Accessories
(for gooseneck mounting)
(4) Carriage bolt nuts
(4) Carriage bolts
(4) Carriage bolt washers
http://support.cyberdata.net/
http://support.cyberdata.net/
http://support.cyberdata.net/
931658C © 2021, CyberData Corporation, ALL RIGHTS RESERVED
