2.3 Intercom Setup

2.3.1 Mechanical Adjustment

The SIP Outdoor Video Intercom with RFID has a mechanical adjustment that ships in the default
position of 0 degrees horizontal
up as shown in
Camera
Operations Guide
(Figure
Figure 2-3 and Figure
Figure 2-2. Mechanical Adjustment at 0 degrees horizontal
931667A
Installing the SIP Outdoor Video Intercom with RFID
2-2), but it allows you to tilt it 15 degrees down or 15 degrees
2-4.
0 degrees
0 degrees
Intercom Setup
Screw used for adjustment
