1.6

Specifications

Specification
Ethernet I/F
Protocol
Power Input
Speaker Output
On-Board Relay
Operating Temperature
Payload Types
SIP Video Payload
Video Lens Angle
b
Dimensions
Weight
Boxed Weight
Part Number
a. Contacts 1 and 2 on the J3 terminal block are only for powering the device from a non-PoE 12VDC
power source as an alternative to Network PoE power. Use of these contacts for any other purpose will
damage the device and void the product warranty.
b. Dimensions are measured from the perspective of the product being upright with the front of the product
facing you.
Operations Guide
Table 1-1. Specifications
10/100 Mbps
SIP RFC 3261 Compatible
PoE 802.3af compliant or +8 to +12VDC @ 1000mA Regulated Power Supply
1 Watt Peak Power
1A at 30 VDC
-10° C to 50° C [14° F to 122° F]
G711, A-law and µ-law
Baseline profile @ 320x240
72 degrees
7.480 in. [190 mm] Length
2.284 in. [58 mm] Width
5.118 in. [130 mm] Height
2.8 lbs. [1.27 kg]
4.0 lbs. [1.81 kg]
Weather Shroud is 1.2 lbs. [0.54 kg]
011414
011215 Weather Shroud (sold separately)
931338B
Product Overview
Specifications
a
CyberData Corporation
5
