Mount the Intercom

Figure A-2. Shroud Dimensions and Mounting Hole Locations

7.638 [194.00]

3.434 [87.23]

ø0.280 [ø7.11]

ø0.854 [ø21.69]

(3 PLACES)

3.380 [85.85]

3.819 [97.00]

7.638 [194.00]

Dimensions are in Inches [Millimeter]

Operations Guide

931338B

CyberData Corporation
