CyberData 011414 Installation Quick Reference

Gooseneck Mounting
Cables to Create
Service Loop
Ground Cable to
Ground Stud
Network Cable to J1
J1
Torx Key
1/4" Washer & Nut
Apply RTV Silicone Sealant Around Mounting Holes and
Backside Perimeter of the Back Box or Weather Shroud
Faceplate Mounting Screws Faceplate
Assembly
Phillips / Security Torx Drive
Note: To mount the intercom, use methods
compliant with local electrical codes.
Note: More installation and mounting
information is illustrated in the Operations Guide.
Caution
Equipment Hazard: Do not use an electric
or power screwdriver to fasten the face plate
and PCB assembly to the gang box. To prevent
over-torque damage to the gasket, do not apply
GENERAL ALERT
more than 10 inch-pounds force. Over-torquing
will cause the gasket to tear, risk moisture intrusion,
and effectively void the manufacturer's warranty.
Contacting CyberData
Corporate Headquarters
CyberData Corporation
Sales: 831-373-2601 ext. 334
3 Justin Court
Support: 831-373-2601 ext. 333
Monterey, CA 93940, USA
Support Website:
RMA Department Contact and Status:
Phone: 831-373-2601
Warranty Information:
Fax: 831-373-4193
https://www.cyberdata.net/
© 2024, CyberData Corporation, ALL RIGHTS RESERVED
Apply RTV Silicone Sealant Around Mounting Holes and
1/4" Carriage Bolt, Washer & Nut
Backside Perimeter of the Back Box or Weather Shroud
(Four Sets Included)
Weather Shroud
Part Number: 011188A
(Sold Separately) Gooseneck
Backbox
Apply RTV Silicone Sealant Around Mounting Holes and
Backside Perimeter of the Back Box or Weather Shroud
Hole Plug Assembly
Ground Cable
Network Cable
All Cable Assemblies and Ground Rod Accessories
are Not Provided.
https://support.cyberdata.net/
https://support.cyberdata.net/
https://support.cyberdata.net/
931336C Quick Reference
Installation Quick Reference
SIP h.264 Video Outdoor Intercom with Keypad
The IP Endpoint Company
011414
Parameter
IP Addressing
a
IP Address
Web Access Username
Web Access Password
a
Subnet Mask
a
Default Gateway
a. Default if there is not a DHCP server present.
Typical System Installation
*More installation and mounting
802.3af Compliant Ethernet Switch
information is available in the
Operations Guide.
SIP h.264 Video Outdoor Intercom with Keypad
Getting Started
• Download the Operations Guide PDF file, from the Downloads tab at the following webpage:
https://www.cyberdata.net/products/011414
• Create a plan for the locations of your Keypad Intercoms.
• WARNING: This product should be installed by a licensed electrician according to all local electrical and building codes.
• WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation
instructions.
• WARNING: The PoE connector is intended for intra-building connections only and does not route to the outside plant.
• WARNING: This enclosure is not rated for any AC voltages!
Parts
Accessory Kit
(1) Assembly
Carriage Bolt Bolts
Carriage Bolt Nuts
Accessory Kit Security Torx MS
Carriage Bolt Washers
Quick Reference
Factory Default Setting
DHCP
10.10.10.10
admin
admin
255.0.0.0
10.0.0.1
IP Phone IP PBX Server
Optional Accessories
(1) 531085* Hole
(1) 1/2-inch EMT
plug assembly
compression
connector with extra
sealing locknut
Mounting Component
Security Torx Key
931336C © 2024, CyberData Corporation, ALL RIGHTS RESERVED
