CyberData 011414 Operation Manual page 25

Connector
JCAM
H_AEC
JBTN
JMIC
JMIC2
JSPKR
JKPAD
JY
JP3
JP4
JP7
JP10
J17
JBT1
JBT2
Operations Guide
Installing the SIP-enabled h.264 Video Outdoor Intercom with Keypad
Table 2-3. Connector Functions
Function
Camera Interface
Echo Cancellation Interface
Call Button LED Interface
Microphone Interface
Second Microphone Interface — Not Used
Speaker Interface
Keypad Interface — Not Used
Sensor Interface — Not Used
Audio Mute — Factory Use Only
Boot from mSD Card — Factory Use Only
EPROM Write Protect — Factory Use Only
Disables the intrusion sensor when installed.
Sitara Card Interface — Factory Use Only
Touch Button -1 Interface — Not Used
Touch Button -2 Interface — Not Used
931338B
