2. On the Button Configuration page, you may enter values for the parameters indicated in
Web Page Item
Dial Mode
Enable Telephone Operation
Enable Cellphone Operation
Enable Speed Dial Operation
Enable Security Operation
Security Mode Settings
Security Code 0
Security Code 1
Security Code 2
Security Code 3
Security Code 4
Security Code 5
Security Code 6
Security Code 7
Security Code 8
Security Code 9
Relay Activation Code
Relay Deactivation Code
Relay Activation Timeout
Play Tone While Relay Active
Allow Telephone Dialout
Call Button
ID
Speed Dial Settings
Speed Dial Timeout
Keypad 1
Operations Guide
Table 2-9.
Table 2-9. Button Configuration Parameters
Description
Dial extensions like a normal telephone. Pressing the call button will start a dial tone.
Pressing the call button in a call will cancel a call.
Enter your extension and press the call button to start the call. Press the call button again
to cancel the call.
In speed dial mode every button can be configured to call a different extension when
pressed.
Security mode allows the user to secure the local relay by requiring a code (up to 8 digits)
to be entered into the device's keypad. Security codes start with the pound key(#) and will
be recognized when the user stops pressing buttons or hits the pound key again.
Up to eight digits using characters 0 through 9 and *.
Up to eight digits using characters 0 through 9 and *.
Up to eight digits using characters 0 through 9 and *.
Up to eight digits using characters 0 through 9 and *.
Up to eight digits using characters 0 through 9 and *.
Up to eight digits using characters 0 through 9 and *.
Up to eight digits using characters 0 through 9 and *.
Up to eight digits using characters 0 through 9 and *.
Up to eight digits using characters 0 through 9 and *.
Up to eight digits using characters 0 through 9 and *.
Activation code used to activate the relay when entered on a phone during a SIP call with
the device. Relay will be active indefinitely, or until the DTMF Relay Deactivation code is
entered. Enter up to 25 digits (* and # are supported).
Code used to deactivate the relay when entered on a phone during a SIP call with the
device. Enter up to 25 digits (* and # are supported).
The time in seconds to activate the relay when a security code is entered. Up to five
numerical digits.
Play a tone when the relay is activated by a security code.
When enabled, the user will be able to use the call button to dial a pre-set extension,
specified on the web page.
Dial this extension when the call button is pressed. Up to 64 characters.
Type the desired Extension ID. Up to 64 characters.
The amount of time you must hold the button before it calls the configured extension.
When this is set to 0 the phone will dial the configured extension as soon as the button is
released.
Dial this extension when the 1 key is pressed.
