Layer light
User's Manual (2D)
NOTE The ruler measurement depends on the position of the
NOTE Make sure that you have selected the right patient and
Green ready
indicator light
TEMPOROMANDIBULAR JOINT (TMJ) EXPOSURE
Imaging position: Ruler measurement
Imaging angle: Submento-vertex exposure
layer light. On retakes always use a ruler to measure
the position. Do not rely on numeric position values.
the panoramic exposure mode in the Planmeca
Romexis program before you take an exposure. Refer
to the Romexis User's Manual.
When you are ready to take an exposure touch the Ready
field on the main display. The X-ray unit will move to the
ready position and the temple supports will automatically
close.
On the exposure button and on the control panel a green
indicator light will come on. Additionally, the word READY
will be shown on the control panel display. The Romexis
program will show the Waiting for Ready message on the
computer screen.
Planmeca ProMax 3D Mid 45
