PANORAMIC EXPOSURE
Bite piece
Frankfort
plane light
34 Planmeca ProMax 3D Mid
NOTE If you are using the chin support, position the patient
NOTE If you are using the chin cup or chin support, use for
Patient position with
chin support
Ask the patient to step forward, grasp the patient handles,
stretch and straighten their back and neck, and bite the
bite piece. The incisal edges of the maxillary and
mandibular teeth must be in the groove in the bite piece.
so that the chin, just below the lower lip, touches the
top bar.
example a cotton roll to ensure that the patient's upper
and lower incisors do not overlap.
The following positioning lights will come on:
Midsagittal
plane light
Layer light
User's Manual (2D)
