7.1

Attaching and removing sensor

Glass windows
Shock
indicator
Attaching sensor to C-arm
User's Manual (2D)
NOTE FOR PROFACE SENSOR:
ProFace sensor
CAUTION Do not drop the sensor. Planmeca limited
Dimax
sensor
Sensor
Locking knob
PREPARATIONS FOR EXPOSURE
Do not touch the glass windows when you hold the
sensor. Fingerprints or other stains on the glass
surface destroy image quality.
warranty does not cover damage which is
due to misuse, e.g. dropping the sensor,
neglect, or any cause other than ordinary
use.
Do not use the sensor if the shock indicator
is red - contact your service technician for
help.
If you have any reason to believe that the
sensor might be faulty, take a test exposure
before taking a patient exposure.
Push the sensor onto the connector on the C-arm.
Turn the locking knob over the fastening mechanism. This
will secure the sensor in position.
Planmeca ProMax 3D Mid 29
