Planmeca ProMax 3D Mid User Manual page 31

Target area up / down
Down
Open / close temple supports
User's Manual (2D)
The target area up and down buttons are used for vertical
fine-adjustment of the target area in 3D imaging. The
buttons are used when the patient is positioned in the X-
ray unit.
The X-ray unit moves slowly when you press the up /
down button. The height of the patient support table is not
Up
changed, i.e. the patient remains in the same position.
Press the temple support button to open the temple
supports in 2D imaging. The temple supports can be
closed by pressing the temple support button again.
PATIENT POSITIONING CONTROLS
Planmeca ProMax 3D Mid 27
