About This Manual

This manual provides information for planning, installing,
programming, and testing an Advent Commercial security
or fire system. When necessary, this manual refers you to
other documentation included with compatible peripherals.
"Appendix A: System Configuration Worksheets" on
page 63 are included for you to record hardware layout and
software programming settings.
About the User Guide
The User Guide contains user worksheets that should be
filled out during the installation and programming of the
system.

Special Installation Requirements

Commercial Fire Panel
The commercial fire panel can be used as a fire warning
system and an intrusion alarm system. When using the com-
mercial fire panel as both a fire warning and intrusion alarm
system, follow the guidelines below:
‰ All aspects of fire and burglary applications must occur in
separate partitions/areas.
‰ All onboard panel inputs and outputs must be used only
for fire or burglary applications. Do not mix fire and bur-
glary applications.
‰ Bus 1 and Bus 2 headers must be used only for fire or bur-
glary applications. Do not mix fire and burglary applica-
tions on inputs and outputs of any bus device.
‰ Some installations may require configurations dictated by
city/state codes, insurance, or Underwriter's Laboratories
(UL). See "UL Listed Installations" for various UL com-
ponent and configuration listings.

UL Listed Installations

This section describes the minimum requirements for differ-
ent UL Listed installations.
Basic System
‰ Commercial Fire (60-562-03 or 60-562-06) Control Panel
‰ SuperBus 2000 VFD (60-804-01) or LCD (60-803-01)
Alphanumeric Touchpad
‰ 24 VAC output, 100 VA Class I, 110VAC, 60 Hz (60-830)
or 24 VAC output, 100 VA Class II, 110VAC, 60 Hz (60-
823) Line Carrier AC Power Transformer
‰ 17.2 AH or 18.0 AH Backup Battery(s) (60-781)
‰ Backup Battery Cable Assemblies (49-475 [red] and 49-
476 [black])
‰ UL listed 4 ohm, 15W Speaker
‰ 2K ohm EOL Resistor(s) (49-467) or (49-454)
Police Station Connected Burglary Alarm Units and
Systems (UL 365)
The system Feature Numbers shall be set as follows in UL
365 listed systems:
Advent Commercial Fire System
Table 1. UL 365 Listed System Settings
Feature
Feature
No.
xx002
Siren Time Out
xx003
Standard Entry Delay
xx004
Exit Delay
yy003
Number of Attempts
yy004
Communication Format
xx088
Report Partition/Area Events
to Central Station
xx092
Enable Auto Force Arming
xx097
Exterior Arming Verification
xx098
Audible Verification at Close
Report
xx102
One-Time Reset Enabled
xx108
Enable Daily Reporting of
Partition Trouble
17034
Phone Test Interval
17036
AC Stable Time
17041
Hours to Delay Before
Reporting AC Failure
17049
RF Supervisory Time A
17069
No Phone Line Attached
17072
Enable RF Jam Detect
17073
Battery Test Interval
17076
Commercial or Residential
Installation
17078
Detect Receiver Failure
17079
Alarm Messages Played at
High Volume
17096
Report System Events
47004
Zone Attributes (edit zones)
xx = Two digit partition number.
yy = Two digit non-pager phone number.
Local Burglar Alarm Units and Systems (UL 609)
System Setup and Programming
The system Feature Numbers shall be set as follows in UL
609 listed systems:
Table 2. UL 609 Listed System Settings
Feature
Feature
No.
xx002
Siren Time Out
yy004
Communication Format
xx088
Report Partition/Area Events
to Central Station
xx092
Enable Auto Force Arming
xx097
Exterior Arming Verification
Required Setting
16 min. minimum
45 sec. maximum
60 sec. maximum
5 min. 10 maximum
0 Contact ID
1-On
0-Off
0-Off
1-On
0-Off
1-On
1 Day
90 sec. maximum
8 hours (or less)
4 hours
0-Off
1-On
1=4 hours
1-Commercial
1-On
1-On (High)
1-On
N/A
Required Setting
16 min. minimum
0 Contact ID
1-On
0-Off
0-Off
1
