Household Fire Warning System Units (UL 985)
Basic system, plus:
‰ Hardwire Smoke Detector (Compatibility Identifier
60-562, 20 per loop maximum):
‰ System Sensor models 2100S, 2100TS, 2100D,
2100TD, 2400, or 2400TH added (learned) into Zone
Type 80.
‰ Sentrol models 429AT, 521B, or 521BXT added
(learned) into Zone Type 80.
The basic system may also include:
‰ SuperBus 2000 RF Transceiver (60-821) for use with
listed wireless signaling devices.
‰ Wireless Smoke Sensor (60-506-319.5 or 60-848-02-95)
added (learned into Zone Type 80.
‰ SuperBus 2000 Printer Automation Module
(60-783) for use with a listed printer.
‰ SuperBus 2000 Dual Phone Line Module (60-768) for
expansion to primary and secondary phone line reporting.
‰ 24V Smoke Loop SnapCard (60-767).
System Setup and Programming
The system Feature Numbers shall be set as follows in
UL 985 listed systems:
Table 4. UL 985 Listed System Settings
Feature
Feature
No.
xx002 Siren Time Out
xx003 Standard Entry Delay
xx004 Exit Delay
yy004 Communication Format
xx085 Enable Police Panic Keys
xx086 Enable Auxiliary/Medical
Panic Keys
xx087 Enable Fire Panic Keys
xx088 Report Partition/Area Events
to Central Station
xx092 Enable Auto Force Arming
xx097 Exterior Arming Verification
xx102 One-Time Reset Enabled
xx108 Enable Daily Reporting of
Partition Trouble
17036 AC Stable Time
17041 Hours to Delay Before
Reporting AC Failure
17049 RF Supervisory Time A
17069 No Phone Line Attached
17072 Enable RF Jam Detect
17073 Battery Test Interval
17076 Commercial or Residential
Installation
17078 Detect Receiver Failure
Advent Commercial Fire System
Table 4. UL 985 Listed System Settings (Continued)
Feature
17079
17096
47004
xx = Two digit partition number.
yy = Two digit non-pager phone number.
Household Burglar-Alarm System Units (UL 1023)
Basic system plus:
‰ Hardwire Magnetic Contact (13-068 or 13-071)
The basic system may also include:
‰ SuperBus 2000 RF Transceiver (60-821) for use with
‰ Wireless Learn Mode Door/Window Sensor (60-362)
‰ SuperBus 2000 Printer or Automation Module
‰ SuperBus 2000 Dual Phone Line Module (60-768) for
System Setup and Programming
The system Feature Numbers shall be set as follows in
Required Setting
UL 1023 listed systems:
4 min. minimum
Feature No.
45 sec. maximum
xx002
60 sec. maximum
xx003
0 Contact ID
xx004
1-On
yy004
1-On
xx088
1-On
xx092
1-On
xx097
0-Off
xx102
0-Off
xx108
0-Off
17036
1-On
17041
90 sec. maximum
17049
8 hours (or less)
17069
4 hours
17072
0-Off
17073
1-On
17076
1-4 hours
17078
0-Off Residential
17079
1-On
17096
Feature
No.
Alarm Messages Play at High
Volume
Report System Events
Zone Attributes (edit zones)
listed wireless signaling devices.
(60-783) for use with a listed printer.
expansion to primary and secondary phone line reporting.
Table 5. UL 1023 Listed System Settings
Feature
Siren Time Out
Standard Entry Delay
Exit Delay
Communication Format
Report Partition/Area Events
to Central Station
Enable Auto Force Arming
Exterior Arming Verification 0-Off
One-Time Reset Enabled
Enable Daily Reporting of
Partition Trouble
AC Stable Time
Hours to Delay Before
Reporting AC Failure
RF Supervisory Time A
No Phone Line Attached
Enable RF Jam Detect
Battery Test Interval
Commercial or Residential
Installation
Detect Receiver Failure
Alarm Messages Play at High
Volume
Report System Events
Required Setting
1-On High
1-On
N/A
Required Setting
6 min. minimum
45 sec. maximum
60 sec. maximum
0 Contact ID
1-On
0-Off
0-Off
1-On
90 sec. maximum
8 hours (or less)
4 hours
0-Off
1-On
1-4 hours
0-Off Residential
1-On
1-On High
1-On
