Create an Enclosure Group

Create an Enclosure Group
Procedure
1 From the top left corner of the HPE OneView UI, choose HP OneView > Enclosure Groups.
2 Click Create enclosure group:
a Enter Solution_EG as the name of the enclosure group.
b Select Solution LIG as the value of Logical interconnect group for interconnect bays 1 and 2.
c Click Create.

Import the HPE BladeSystem c7000 Enclosures

Procedure
1 From the top left corner of the HPE OneView UI, choose HP OneView > Enclosures.
2 Click Add enclosure and enter the following information:
• OA IP address or host name: <<enclosure_1_oa_1_ip>>.
• Action: Add enclosure for management.
• Username: admin.
• Password: <<enclosure_1_password>>.
• Enclosure group: Solution_EG.
• Licensing: HP OneView Advanced.
• Firmware baseline: Select the HPE SPP that you uploaded earlier.
3 Click Add.
It takes several minutes for HPE OneView to inventory, configure, and update the firmware on the Onboard
Administrator and Virtual Connect modules, if needed.
4 Repeat the procedure to import all enclosures into HPE OneView.

Creating Profiles for the HPE DL360 Gen9 Management Servers

When creating server profiles for HPE ProLiant DL360 Gen9 management servers, ensure that the
management server for which you are creating the profile does not have any VMs on it. At this point in the
configuration of the solution, only the first management server (<<mgmt_server_1_hostname>>) should have
VMs, but double-check to be sure. Before you apply a profile to a management server, you must migrate all
VMs in that server to another management server.
The procedures in this section focus on the second management server (<<mgmt_server_2_hostname>>),
but the same steps apply to all of the other management servers. After you apply the profile to the second
management server and the server has rejoined the VMware cluster in VMware vCenter, apply the profile to
the other management servers in the solution. Ensure that all VMs are migrated off of the servers and that
they are shut down before you try to apply the profiles.
Leave the first management server for last because you will need to vacate all VMs off of it, including the
HPE OneView VM, before you can apply the profile to this server.
Shut Down the Management Server
Procedure
1 Using a web browser, log in to the VMware vSphere Web Client.
2 From the Home tab, click Hosts and Clusters.
3 In the left pane, expand <<vcenter_dc_name>> > <<vcenter_mgmt_cluster_name>>.
4 Right-click <<mgmt_server_2_hostname>> and select Enter Maintenance Mode.
©
