Configure iLO
b Power up the server.
c Press F9 when the server POST displays F9 System Utilities on the bottom of the screen.
d Select System Configuration and press Enter.
e Select BIOS/Platform Configuration (RBSU) and press Enter.
2 Configure the date and time:
a Select Date and Time and press Enter.
b Select the month digits on Date and press Enter. Enter the month in the mm format and press Enter.
c Use the right arrow to select the day digits and press Enter. Enter the day in the dd format and press
Enter.
d Use the right arrow to select the year digits and press Enter. Enter the year in the yyyy format and
press Enter.
e Select the hour digits on Time and press Enter. Enter the hour in the hh format and press Enter.
f
Use the right arrow to select the minute digits and press Enter. Enter the minutes in the mm format
and press Enter.
g Select Time Zone and press Enter. Select the appropriate time zone and press Enter.
h Press F10 to save. Enter Y to save and exit. After the Changes Saved pop-up window displays, press
Enter.
3 Configure the iLO IP information – IP Information:
a Press ESC to go to the BIOS menu and again to go to the System Configuration menu.
b Select iLO 4 Configuration Utility and press Enter.
c Select Network Options and press Enter.
d Select DHCP Enable and press Enter. In the pop-up, select OFF and press Enter.
e Select DNS Name and press Enter. Enter <<mgmt_server_1_ilo_hostname>> and press Enter.
f
Select IP Address and press Enter. Enter <<mgmt_server_1_ilo_ip>>and press Enter.
g Select Subnet Mask and press Enter. Enter <<mgmt_net_netmask>> and press Enter.
h Select Gateway IP Address and press Enter. Enter <<mgmt_net_gw>> and press Enter.
i
Press F10 to save the configuration.
j
Enter Y to save and exit.
k Press Enter on the iLO Needs to Reset pop-up window.
l
Wait 30 seconds for the iLO to reset, and then try to reconnect to the iLO and open the remote console.
m Press Enter on the iLO is Resetting pop-up window again and then ESC.
n Press ESC to go to the iLO 4 Configuration Utility menu, again to go to the Systems Configuration
menu, and again at the System Utilities menu.
o Press Enter to exit RBSU and Enter again to reboot.
p Select Reboot the System and press Enter to reboot the system.
4 Configure the iLO IP information – Advanced Network Options:
a Press F9 when the server POST displays F9 System Utilities at the bottom of the screen.
b Select System Configuration and press Enter.
c Select iLO 4 Configuration Utility and press Enter.
d Select Advanced Network Options and press Enter.
e Select Gateway from DHCP and press Enter. In the pop-up, select Disabled and press Enter.
f
Select DHCP Routes and press Enter. In the pop-up window, select Disabled and press Enter.
g Select Gateway from DHCP and press Enter. In the pop-up window, select Disabled and press Enter.
h Select DNS from DHCP and press Enter. In the pop-up window, select Disabled and press Enter.
i
Select DNS Server 1 and press Enter. Enter <<mgmt_net_dns1>> and press Enter.
j
Select WINS from DHCP and press Enter. In the pop-up window, select Disabled and press Enter.
k Select Domain Name and press Enter. In the pop-up window, enter <<mgmt_net_domain_name>>
and press Enter.
©
