Create Network Sets

Name
FT_B
VM_Traffic_A
VM_Traffic_B
4 Create additional Ethernet networks as needed.
5 Use the information in the following table to create SAN networks.
Table 9: HPE-recommended Fibre Channel networks for fabric-attached networks
Name Type
SAN_A FCoE
SAN_B FCoE
6 Create additional SAN networks as needed.
7 If additional networks are not required, click Cancel in the Create Network window.
Create Network Sets
Procedure
1 From the top left corner of the HPE OneView UI, choose HP OneView > Network Sets.
2 Click Create network set to create the Mgmt_Set_A network set:
a Name: Mgmt_Set_A.
b Preferred Bandwidth: 1 Gb/s.
c Maximum Bandwidth: 20 Gb/s.
d Click Add networks and add the following networks to this network set:
Tip You can hold the Ctrl key to select multiple networks at one time.
• Mgmt_A
• Deployment_A
• Any additional management networks that you have created for side A
e Select the Untagged checkbox for the Deployment_A network.
3 Click Create+ to create the Mgmt_Set_B network set:
a Name: Mgmt_Set_B.
b Preferred Bandwidth: 1 Gb/s.
c Maximum Bandwidth: 20 Gb/s.
d Click Add networks and add the following networks to this network set:
• Mgmt_B
©
Copyright 2017 by Nimble Storage, Inc. All rights reserved.
Type VLAN VLAN ID
Ethernet Tagged <<compute_ft_net_vlan>>
Ethernet Tagged <<vm_produc-
tion_net_1_vlan>>
Ethernet Tagged <<vm_produc-
tion_net_1_vlan>>
Associate with SAN
VSAN
<<net_fcoe_vsan_a_id>>
VSAN
<<net_fcoe_vsan_b_id>>
Documentation Feedback
Purpose
Fault toler-
ance
General
General
VLAN ID
<<fcoe_san_a_vlan>>
<<fcoe_san_b_vlan>>
Preferred Maximum
Bandwidth Bandwidth
(Gb) (Gb)
2 20
9 20
9 20
Preferred Maximum
Bandwidth Bandwidth
(Gb) (Gb)
8 20
8 20
