Uplink into the Existing Network Infrastructure

3 Create a bridge aggregation for each management server.
interface Bridge-Aggregation 11
description <<mgmt_server_1_hostname>>
quit
interface Bridge-Aggregation 12
description <<mgmt_server_2_hostname>>
quit
interface range name mgmt_servers interface Bridge-Aggregation11
Bridge-Aggregation12
quit
interface range Ten-GigabitEthernet 1/2/17 Ten-GigabitEthernet 2/2/17
port link-aggregation group 11
quit
interface range Ten-GigabitEthernet 1/2/18 Ten-GigabitEthernet 2/2/18
port link-aggregation group 12
quit
interface range name mgmt_servers
port link-type trunk
undo port trunk permit vlan 1
port trunk pvid vlan <<deployment_net_vlan>>
port trunk permit vlan <<deployment_net_vlan>> <<mgmt_net_vlan>>
<<mgmt_vmotion_net_vlan>> <<fcoe_san_a_vlan>> <<fcoe_san_b_vlan>>
quit
save
Note The bridge aggregations created in this procedure do not become fully operational until the
management and compute servers are deployed with VMware vSphere as described in this guide.
Uplink into the Existing Network Infrastructure
Depending on the available network infrastructure, several methods and features can be used to uplink the
HPE Converged Architecture 700 with Nimble Storage environment. HPE recommends using bridge
aggregations to uplink the HPE FlexFabric 5940-4Slot switches in the HPE Converged Architecture 700 with
Nimble Storage environment into the infrastructure.
The preceding procedures can be used to create an uplink bridge aggregation to the existing environment.
After configuration is complete, be sure to run the save command to save the configuration on each switch.
©
