Configure the FCoE Mode and VSANs

spanning tree ensures that if spanning tree is enabled on the switch as part of the configuration, these
ports directly transition to the forwarding state in the spanning tree topology.
interface range FortyGigE 1/1/1 to FortyGigE 1/1/3 FortyGigE 2/1/1 to FortyGigE
2/1/3 Ten-GigabitEthernet 1/2/17 to Ten-GigabitEthernet 1/2/18
Ten-GigabitEthernet 2/2/17 to Ten-GigabitEthernet 2/2/18
priority-flow-control auto
priority-flow-control no-drop dot1p 3
qos trust dot1p
stp edged-port
2 Configure LLDP and DNCX TLV advertising on the interfaces.
Run the following commands in system-view while still on the interface range from step 1 of this procedure:
lldp tlv-enable dot1-tlv dcbx
qos apply policy DCBX outbound
3 Enable weighted round robin (WRR) on the interfaces, setting 50 percent of the bandwidth to networking
for best effort (be) and 50 percent of the bandwidth to storage traffic for assured forwarding (af1).
Set the rest of the WRR values to strict priority because they are not being used. Run the following
commands in system-view while still on the interface range from step 1 of this procedure:
qos wrr be group 1 byte-count 5
qos wrr af1 group 1 byte-count 5
qos wrr af2 group sp
qos wrr af3 group sp
qos wrr af4 group sp
qos wrr ef group sp
qos wrr cs6 group sp
qos wrr cs7 group sp
quit
save
Configure the FCoE Mode and VSANs
This procedure enables FCoE mode on the switch and sets it to Fibre Channel forwarder (FCF) mode. It also
creates the VSANs for FCoE SAN A and FCoE SAN B and attaches them to the appropriate VLAN IDs.
Procedure
1 In system-view, set the FCoE mode to FCF.
fcoe-mode fcf
2 Create the VSAN for FCoE SAN A and set the domain ID.
vsan <<net_fcoe_vsan_a_id>>
domain-id <<net_fcoe_vsan_a_domain_id>> preferred
Non-disruptive reconfiguration or isolating the switch may be performed.
Continue? [Y/N]:y
quit
©
