Configure Multi-Active Detection and Remote Access to the Switch

[HPE] irf-port-configuration active
[HPE] interface range FortyGigE 2/1/7 to FortyGigE 2/1/8
[HPE-if-range] undo shutdown
[HPE-if-range] quit
[HPE] save
The current configuration will be written to the device. Are you sure? [Y/N]:y
Please input the file name(*.cfg)[flash:/startup.cfg]
(To leave the existing filename unchanged, press the enter key):
flash:/startup.cfg exists, overwrite? [Y/N]:y
Validating file. Please wait...
Saved the current configuration to mainboard device successfully.
[HPE]
6 Back at HPE FlexFabric 5940-4Slot switch A, enable the IRF ports on switch A.
<HPE> system-view
[HPE] irf-port-configuration active
[HPE] interface range FortyGigE 1/1/7 to FortyGigE 1/1/8
[HPE-if-range] undo shutdown
[HPE-if-range] quit
7 Allow switch B to reboot to merge into the IRF fabric.
From this point on, all configurations happen only on switch A. No further configuration is needed on switch
B because the control and management planes have been merged as a part of the IRF configuration.
Configure Multi-Active Detection and Remote Access to the Switch
HPE recommends implementing a multi-active detection (MAD) mechanism, which is useful for these purposes:
• To detect the presence of multiple identical IRF fabrics
• To handle collisions
• To recover from faults in the unlikely event of an IRF split or failure
For more information, see the
use the management links to configure MAD Bidirectional Forwarding Detection (BFD).
Note The switch configuration code in this procedure does not include switch prompts.
Procedure
1 From system-view, run the following commands, substituting the values from the configuration worksheet.
interface M-GigabitEthernet 0/0/0
ip address <<net_switch_mgmt_ip>> <<mgmt_net_netmask>>
mad bfd enable
mad ip address <<net_switch1_mad_ip>> <<mad_net_netmask>> member 1
mad ip address <<net_switch2_mad_ip>> <<mad_net_netmask>> member 2
quit
ip route-static 0.0.0.0 0.0.0.0 <<mgmt_net_gw>>
local-user admin
password simple <<net_switch_admin_password>>
authorization-attribute user-role network-admin
service-type ssh terminal
©
Copyright 2017 by Nimble Storage, Inc. All rights reserved.
HPE FlexFabric 5940 IRF Configuration
Documentation Feedback
Guide. This guide explains how to
