RSA3303A & RSA3308A Service Manual
d. Repeat substeps a through c until all frequency settings listed in
Table 4- -6 are checked.
Table 4- 6: Spurious measurement
Band
Baseband
RF (RSA3303A) / RF1 (RSA3308A)
RF2 (RSA3308A only)
RF3 (RSA3308A only)
3. Disconnect the test equipment: Disconnect the cable at the analyzer input.
Frequency
Spurious response
10 MHz
- - 73 dBc
2 GHz
- - 73 dBc
5 GHz
- - 70 dBc
7 GHz
- - 70 dBc
Performance Tests
4- 41
