Tektronix RSA3303A Service Manual page 144

Removal and Installation Procedures
6- 10
Equipment Required. Most modules in this analyzer can be removed with a
screwdriver with a size #2, Phillips tip. Use this tool whenever a procedure step
instructs you to remove or install a screw unless a different size screwdriver is
specified in that step. All equipment required to remove and reinstall a module
are listed in the first step of each procedure.
Table 6- 5: Tools required for module removal
Item
No. Name
1 Screwdriver handle
2 #1 Phillips tip
3 #2 Phillips tip
4 Flat-bladed screwdriver
5 SMA torque driver
6 Long type bit
7 Nutdriver, 12 mm
8 Nutdriver, 14 mm
9
9 Nutdriver, inch
@
1 6
1
10 Wrench, inch
@
1 6
5
11 Wrench, inch
@
1 6
12 Needle-nose pliers
13 Retaining ring pliers
14 Angle-tip tweezers
15 Pliers
16 Soldering iron
17 Solder wick
18 Adhesive
Description
1
Accepts inch hex-head driver tips
@
4
Phillips-driver bit for #1 size screw
heads
Phillips-driver bit for #2 size screw
heads
Screwdriver for removing standard-
headed screws
Accepts SMA hex-head driver bits
Long type bit (H 8 mm×L 130 mm)
for SMA/3.5 mm connector
Standard tool
Standard tool
Standard tool
Standard tool
Standard tool
Standard tool
Standard tool;
1
1 inch minimum throw
@
8
Standard tool
Standard tool
Standard tool
Standard tool
TRA-CON: Tra-Bond #BA-2114
RSA3303A & RSA3308A Service Manual
Tektronix
part number
003-1423-91
003-1422-00
