Removal and Installation Procedures
Floppy Disk Drive
A62 Front Connection
Board
6- 36
1. Assemble equipment and locate module to be removed:
a. You will need a screwdriver with size Phillips #1 and #2 tips (Items 1, 2,
and 3).
b. Locate the floppy disk drive in the CPU board and disk modules
diagram, Figure 6- -4, page 6- -14.
2. Remove the disk bracket containing the floppy disk drive using step 4 in the
hard disk drive removal procedure on page 6- -34.
3. Remove the floppy disk drive: See Figure 6- -18.
a. Unplug the floppy driver connector (ribbon interconnect cable) that
connects the disk drive to J106 on the A62 Front connection board.
b. Using a screwdriver with size Phillips #1 tip, remove the four screws
securing the disk drive to the bracket. Pull out the disk drive.
4. Reinstallation: Reverse steps 2 and 3 to reinstall the floppy disk drive.
1. Assemble equipment and locate module to be removed:
a. You will need a #2 Phillips screwdriver (Items 1 and 3).
b. Locate the A62 Front connection board in the CPU board and disk
modules diagram, Figure 6- -4, page 6- -14.
2. Remove the disk bracket containing the A62 Front connection board using
step 4 in the hard disk removal procedure on page 6- -34.
3. Remove the A62 Front connection board: See Figure 6- -18.
a. Remove the two screws securing the shield bracket over the A62 board
to the disk bracket.
b. Remove the two screws securing the A62 board to the disk bracket.
Lift the board up away.
4. Reinstallation: Reverse steps 2 and 3 to reinstall the A62 board.
