Specifications

Table 1- 10: Frame time

Characteristics
Frame time (Real Time S/A, Demod, and Time modes)
20 MHz span (Baseband)
15 MHz span (RF, RF1 to 3)
10 MHz span
5 MHz span
2 MHz span
1 MHz span
500 kHz span
200 kHz span
100 kHz span
50 kHz span
20 kHz span
10 kHz span
5 kHz span
2 kHz span
1 kHz span
500 Hz span
200 Hz span
100 Hz span

Table 1- 11: Digital demodulation (Option 21 only)

Characteristics
Demodulator
Carrier type
Modulation format
Measurement filter
Reference filter
Filter parameter
Maximum symbol rate
Standard setup
1- 8
Description
40 ms
40 ms
80 ms
160 ms
320 ms
640 ms
1.28 ms
3.2 ms
6.4 ms
12.8 ms
32 ms
64 ms
128 ms
320 ms
640 ms
1.28 s
3.2 s
6.4 s
Description
Continuous and Burst
BPSK, QPSK, π/4 shift DQPSK, 8PSK, 16QAM, 64QAM, 128QAM, 256QAM,
GMSK, GFSK, ASK and FSK
Root cosine
Cosine, Gauss
α/BT: 0.0001 to 1, 0.0001 step
12.8 Msps
PDC, PHS, NADC, TETRA, GSM, CDPD, and Bluetooth
RSA3303A & RSA3308A Service Manual
