Replaceable Parts
Replaceable parts list
Fig. &
Tektronix
index
number part number
10- - 10
- - 1 174- - C038- - XX
- - 2 211- - A273- - XX
- - 3 148- - A079- - XX
- - 4 174- - C039- - XX
- - 5 174- - C040- - XX
- - 6 386- - A874- - XX
- - 7 174- - B944- - XX
- - 8 174- - C037- - XX
- - 9 211- - A151- - XX
- - 10 119- - A960- - XX
- - 11 671- - B190- - XX
- - 12 119- - A864- - XX
- - 13 407- - A725- - XX
- - 14 211- - A152- - XX
- - 15 211- - 0871- - XX
- - 16 211- - A151- - XX
- - 17 407- - A726- - XX
- - 18 119- - B186- - XX
- - 19 211- - A152- - XX
- - 20 119- - B175- - XX
- - 21 348- - 0949- - XX
- - 22 174- - B949- - XX
- - 23 174- - B948- - XX
10- 22
Serial No. Serial No.
effective discont'd Qty
1
4
1
1
1
1
1
1
4
2
1
1
1
2
2
3
1
1
4
1
1
1
1
Name & description
FOR RSA3308A ONLY
CABLE ASSY,RF:SEMI- - RIGID,W121,ATT TO SW
SCREW,MACHINE:M2.5X18 L,PNH,STL,NI PL,CROSS REC,W/FLAT(KOGATA)&
LOCK WASHER
RELAY,COAX:COIL 12V,DC- - 18GHZ(IL<0.5DB),VSWR 1.5,SMA CONN
CABLE ASSY,RF:SEMI- - RIGID,W122,SW TO FINE ATT
CABLE ASSY,RF:SEMI- - RIGID,W123,SW TO YTF
PLATE,BASE:RF- - 1,AL T=1.6
CABLE,RF:SEMI- - RIGID,W101,N- - CON TO SW
CABLE ASSY,RF:SEMI- - RIGID,W120,SW TO ATT
SCREW,MACHINE:M2.5X6MM L,PNH,STL,ZN- - C,CROSS REC,W/KOGATA- - PLAIN&
SPLIT WSHR
ATTENUATOR,FXD:3DB,DC- - 8GHZ,50 OHM,1W,SMA CONN
CIRCUIT BD ASSY: A150 YTF I/F,389- - B192- - XX WIRED
YTF UNIT:YIG FILTER,3.5- - 8GHZ,4STAGE,30MHZ
BRACKET:YTF,AL T=1.6
SCREW,MACHINE:M2.5X8MM L,PNH,STL,NI PL,CROSS REC, W/KOGATA- - PLAIN&
SPLIT WSHR
SCREW,MACHINE:M3X6MM L,PNH,STL,MFZN- - C,CROSS REC W/FLAT&LOCK WASHER
SCREW,MACHINE:M2.5X6MM L,PNH,STL,ZN- - C,CROSS REC,W/KOGATA- - PLAIN&
SPLIT WSHR
BRACKET:ATT,AL T=1.6
ATTENUATOR:MODULE,STEP ATT,0- - 70DB,10DB STEP,DC- - 8GHZ,50 OHM,
COIL 24V 0.72A
SCREW,MACHINE:M2.5X8MM L,PNH,STL,NI PL,CROSS REC,W/KOGATA- - PLAIN&
SPLIT WSHR
MODULE,RF:DOWN CONVERTER,FINE ATT,WCA230A&WCA280A
GROMMET,PLASTIC:NYLON,BLACK,RING,15MM ID
CA ASSY,RF:50OHM,SEMI- - RIGID,W106,FINE ATT TO SW
CA ASSY,RF:50OHM,SEMI- - RIGID,W105,YTF TO A310
RSA3303A & RSA3308A Service Manual
