Replaceable Parts
Replaceable parts list
Fig. &
Tektronix
index
number part number
10- - 14 OPTION 1R ONLY
- - 1 333- - 4538- - XX
- - 2 407- - 5226- - XX
- - 3 407- - 5223- - XX
- - 4 407- - 5224- - XX
- - 5 367- - 0525- - XX
- - 6 351- - 0313- - XX
- - 7 351- - 0241- - XX
- - 8 211- - A039- - XX
- - 9 212- - 0518- - XX
- - 10 212- - 0509- - XX
- - 11 212- - 0574- - XX
- - 12 - - - - - - - - - - - - - - - -
- - 13 335- - 0391- - XX
10- 30
Serial No. Serial No.
effective discont'd Qty
1
1
1
1
2
1
1
8
15
6
4
12
1
Name & description
PANEL,FRONT BLANK PANEL FOR RACK
BRACKET HOLDING CABLE
BRACKET SLIDE GUIDE LEFT
BRACKET SLIDE GUIDE RIGHT
HANDLE CARRYING
GUIDE RACK MOUNT
SLIDE DWR EXT
SCREW M4X14MM,SEMS
SCREW 10- - 32X0.312INCH,PNH
SCREW 10- - 32X0.625INCH,PNH
SCREW 10- - 32X0.438INCH,FLH
SCREW 10- - 32X0.354INCH,TRUSS (Included in the slide assembly (Figure index 10- - 14- - 7))
MARKER,IDENT;SAFETY LABEL
