Tektronix RSA3303A Service Manual page 100

Performance Tests
Frequency readout test
Frequency
10 MHz
2 GHz
5 GHz
7 GHz
Spurious response test
Frequency
10 MHz
2 GHz
5 GHz (RSA3308A only)
7 GHz (RSA3308A only)
Displayed average noise level test
Frequency
10 MHz
2 GHz
3 GHz
7 GHz (RSA3308A only)
Residual response test
Band
Baseband
RF (RSA3303A only)
RF1 (RSA3308A only)
RF2 (RSA3308A only)
RF3 (RSA3308A only)
4- 52
Measurement Low limit
Marker 9,999 kHz
Carrier frequency meas. 9,999,998.8 Hz
Marker 1,999,998.8 kHz
Carrier frequency meas. 1,999,999,790 Hz
Marker 4,999,998.5 kHz
Carrier frequency meas. 4,999,999,490 Hz
Marker 6,999,998.3 kHz
Carrier frequency meas. 6,999,999,290 Hz
Low limit
Low limit
Frequency range Low limit
1 to 20 MHz
0.5 to 3 GHz
0.5 to 3.5 GHz
3.5 to 6.5 GHz
5 to 8 GHz
Test result High limit
10,001 kHz
10,000,001.2 Hz
2,000,001.2 kHz
2,000,000,210 Hz
5,000,001.5 kHz
5,000,000,510 Hz
7,000,001.7 kHz
7,000,000,710 Hz
Test result High limit
- - 73 dBc
- - 73 dBc
- - 70 dBc
- - 70 dBc
Test result High limit
- - 151 dBm/Hz
- - 150 dBm/Hz
- - 150 dBm/Hz
- - 142 dBm/Hz
Test result High limit
- - 93 dBm
- - 90 dBm
- - 90 dBm
- - 85 dBm
- - 85 dBm
RSA3303A & RSA3308A Service Manual
