Specifications
Table 1- 11: Digital demodulation (Option 21 only) (Cont.)
Characteristics
π/4 DQPSK
Center frequency = 1 GHz
Center frequency = 2 GHz
Center frequency = 3 GHz
Center frequency = 5 GHz
(RSA3308A only)
16QAM
Center frequency = 1 GHz
Center frequency = 2 GHz
Center frequency = 3 GHz
Center frequency = 5 GHz
(RSA3308A only)

Table 1- 12: Analog demodulation

Characteristics
Accuracy (Typical)
AM demodulation
PM demodulation
FM demodulation
1- 10
Description
EVM (Typical) Symbol rate
0.6% 100 kHz
0.6% 1 MHz
1.2% 4 MHz
2.7% 10 MHz
0.6% 100 kHz
0.6% 1 MHz
1.2% 4 MHz
2.7% 10 MHz
0.7% 100 kHz
0.7% 1 MHz
1.5% 4 MHz
2.9% 10 MHz
0.7% 100 kHz
0.7% 1 MHz
1.5% 4 MHz
3.0% 10 MHz
EVM (Typical) Symbol rate
0.9% 100 kHz
0.5% 1 MHz
1.2% 4 MHz
2.2% 10 MHz
0.9% 100 kHz
0.5% 1 MHz
1.2% 4 MHz
2.2% 10 MHz
0.9% 100 kHz
0.5% 1 MHz
1.2% 4 MHz
2.5% 10 MHz
0.9% 100 kHz
0.5% 1 MHz
1.2% 4 MHz
2.5% 10 MHz
Description
±2% (- - 10 dBfs input at center, 10 to 60% modulation depth)
±3° (- - 10 dBfs input at center)
±1% of span (- - 10 dBfs input at center)
