Rating Plate; Date Of Manufacture; Assignment Of Characters To The Month And Year Of Manufacture - Siemens simovert masterdrives Operating Instructions Manual

08.2008
NOTE

Rating plate

Date of manufacture

Siemens AG 6SE7087-2JK50
SIMOVERT MASTERDRIVES
The derating of the permissible rated current for installation altitudes of
over 1000 m and at ambient temperatures below 40 °C is calculated as
follows:
Total derating = Derating
K = K x K
1 2
It must be borne in mind that total derating must not be greater than 1!
Example: Altitude: 3000 m
Ambient temperature: 35 °C
⇒ Total derating = 0.845 x 1.125 = 0.95
Rating plate
Fig. 11-2
The date of manufacture can be derived as follows:
Character Year of manufacture:
U
V
W
X
Table 11-2

Assignment of characters to the month and year of manufacture

Operating Instructions
x Derating
altitude ambient temperature
Character
2006 1 to 9
2007 O
2008 N
2009 D
Technical Data
K = 0.845
1
K = 1.125
2
Unit designation
List of unit options
Year of manufacture
Month of manufacture
Month of manufacture
January to September
October
November
December
11-3
