Siemens AG 6SE7087-2JK50
SIMOVERT MASTERDRIVES
Num. ordin. motore
(MLFB)
1FT6086-8WK7
1FT6105-8WC7
1FT6105-8WF7
1FT6108-8WB7
1FT6108-8WC7
1FT6108-8WF7
per impiego futuro
1FT6108-8AF7
1FT6105-8SH7
1FT6136-6SF7
1FT6021-6AK7
1FT6024-6AK7
1FT6163-8SB7
1FT6163-8SD7
1FT6168-8SB7
per impiego futuro
1FK7022-5AK71
1FK7032-5AK71
1FK7040-5AK71
1FK7042-5AF71
1FK7042-5AK71
1FK7060-5AF71
1FK7060-5AH71
1FK7063-5AF71
1FK7063-5AH71
1FK7080-5AF71
1FK7080-5AH71
1FK7083-5AF71
1FK7083-5AH71
1FK7100-5AF71
1FK7101-5AF71
1FK7103-5AF71
1FK7042-5AH71
Istruzioni di servizio
Velocità Coppia
n [1/min] M [Nm]
n n
6000 44,0
2000 82,0
3000 78,0
1500 116,0
2000 115,0
3000 109,0
3000 37,0
4500 40,0
3000 145,0
6000 0,3
6000 0,5
1500 385,0
2500 340,0
1500 540,0
6000 0,6
6000 0,75
6000 1,1
3000 2,6
6000 1,5
3000 4,7
4500 3,7
3000 7,3
4500 3,0
3000 6,2
4500 4,5
3000 10,5
4500 3,0
3000 12,0
3000 15,5
3000 14,0
4500 2,2
Parametrizzazione
Corrente Numero
I [A] paiapoli
n
58,0 4
60,0 4
82,0 4
43,0 4
57,0 4
81,0 4
25,0 4
41,0 4
104,0 3
1,1 3
0,9 3
136,0 4
185,0 4
174,0 4
1,4 3
1,4 3
1,7 4
1,9 4
2,4 4
3,7 4
4,1 4
5,6 4
3,8 4
4,4 4
4,7 4
7,4 4
3,6 4
8,0 4
10,5 4
12,0 4
2,2 4
