08.2008
MLFB
6SE7035-1EK 0-1AA0
6SE7036-0EK 0-1AA0
6SE7037-0EK 0-1AA0
Fan voltage/frequency
Curent requirement - type K
Sound dpressure level IP20
Sound pressure level IP42
Sound pressure level IP54
Siemens AG 6SE7087-2JK50
SIMOVERT MASTERDRIVES
Volumetric Differential
flow pressure
[l/min] [Pa]
27
10470
28
11260
30
12920
Table 11-8

Characteristic data of AC units 380 V - 480 V

= 5 corresponds to MASTERDRIVES Motion Control
= 7 corresponds to MASTERDRIVES Motion Control Performance 2
* The sound level was determined under the following boundary conditions:
Distance to the unit 1 m, height above floor level 1 m, distance to the next reflecting
wall 4 m, room height 6m.
The chassis were installed in Siemens 8MC cabinets without any special
soundproofing measures.
V/Hz
A
dB(A)
dB(A)
dB(A)
Table 11-9

Operating data of fan - type K

Type
K
Table 11-10

Water contents of the heat sinks (+/- 10 %)

Operating Instructions
Sound Sound Sound
level level level
IP20 IP42 IP54
[dBA]* [dBA]* [dBA]*
76 75 72
76 75 72
76 75 72
230/50
2.45
see table
see table
see table
Water contents (litres)
2.1
Technical Data
Water Dissi-
heating pated
losses
[k] [kW]
4.5 6.9
4.5 8
4.8 9.3
230/60
3.6
see table +1.0
see table +0.5
see table
11-21
