Installation
5.1.2

Installing units of type K

5-4
Mounting surface
350 mm
Side view
Fig. 5-3

Dimension drawing for type G

Mounting surface
550
Side view
Fig. 5-4

Dimension drawing for type K

25 mm
119 mm 270 mm
508 mm
Front view
Cutout for M8 / M10 screw
Oblong holes 9 x 15
for M8 screw
25
800
Front view
Operating Instructions
09.2006
Cutout for
M8 screw
6SE7087-2JK50 Siemens AG
SIMOVERT MASTERDRIVES
