Application of
Feed unit
Disassembly
2
Disassembly of Lower shaft B assy
1. Remove the lower shaft bushing from the lower shaft B sub assy.
2. Remove the retaining ring E6 to remove the timing pulley D from the lower shaft B sub assy.
Retaining ring E6
Timing pulley D
Lower shaft bushing
Lower shaft B sub assy
3 - 10
