Parameter Group 8 - Multifunction output terminal and output signal
Multifunction analog output control:
8-00： ： ： ： Analog Output Voltage Mode： ： ： ：
0000: Output frequency
0001: Frequency Setting
0002: Output voltage
0003: DC Bus Voltage
0004: Motor current
0005: FEEDBACK Signal of PID
8-01： ： ： ： Analog Output Gain = 0 ~ 200%
The multifunction analog output terminal of the terminal block (TM2), is 0~10Vdc analog output. The
output type is determined by the 8-01. The function of 8-01 is: when there is tolerance for the external
voltage meter and peripheral equipment, please regulate 8-00.
The FEEDBACK value of PID (That is the input voltage and current of S6) outputs analog value from
FM+ terminal. ( decide to parameter 4-06) The value is corresponding to the input signal 0~10V(0 ~ 20 mA)
or 2~10V (4~20mA).
※ Note: The max output voltage is 10V due to the circuit, even the output voltage should be higher than
10V.
Multifunction output terminals control:
8-02： ： ： ： RELAY1(R1C， ， ， ， R1B， ， ， ， R1A terminal on TM2)
8-03： ： ： ： RELAY2(R2C， ， ， ， R2A terminal on TM2)
0000: Run
0001: Frequency Reached (Target Frequency) (Set Frequency ± 8-05)
0002: Set Frequency (8-04 ± 8-05)
0003: Frequency Threshold Level (> 8-04) - Frequency Reached
0004: Frequency Threshold Level (< 8-04) - Frequency Reached
0005: Over torque Threshold Level
0006: Fault
0007: Auto-restart
0008: Momentary AC Power Loss
0009: Rapid Stop Mode
0010: Coast-to-Stop Mode
0011: Motor Overload Protection
0012: Drive Overload Protection
0013: PID Feedback Signal Break
0014: PLC Operation
0015: Power On
8-04： ： ： ： Frequency Reached Output Setting =0 ~ 650Hz
8-05： ： ： ： Frequency Output Detection Range =0 ~ 30Hz
operation mode
