Symbol
S1
S2
Multifunction input terminals(refer to 5-00 ~ 5-04 description)
S3
(S5 = Encoder input terminal, the Encoder voltage range: 19.2V~24.7V)
S4
S5
Multifunction input terminals (Digital terminal H level:>8V, L level:<2V, PNP only)
S6
or analog input terminal AI2(0~10Vdc/4~20mA)( refer to 5-05 description)
SW function
Descriptions of
SW2/SW3
V
I I I I
V
I I I I
SW1
Function Description
Type of external signal
0~10VDC analog signal
0~20mA analog signal
Type of external signal
NPN (SINK) input
PNP (SOURCE) input
3-14
Chapter 3 Ambient Environment and Installation
Remarks
External control is available as 1-
06=0002
Remarks
Factory default
