6.3 Braking unit and braking resistor
VAT200 series braking current calculation
GE Motor
Drive KW Braking Unit (s)
U20_N00K4 0,4
U20_N00K7 0,75
U20_N01K5 1,5
U20_N02K2 2,2
U20_N04K0 4
U20_N05K5 5,5
U20_N07K5 7,5
U203X00K7 0,75
U203X01K5 1,5
U203X02K2 2,2
U203X04K0 4
U203X05K5 5,5
U203X07K5 7,5
U203X11K0 11
U203X15K0 15
U203X18K5 18,5
U203X22K0 22
U203X30K0 30
U203X37K0 37
2x U200ABU430
U203X45K0 45
2x U200ABU430
U203X55K0 55
2 x U200ABU430
For Detailed information ask your supplier
For drives 18.5KW and above, please add external Braking Unit: for 400V series: U200ABU430
For drives 37KW and above need to use two Braking units. Each must be fitted with
corresponding braking resistor
External GE Encapsulate Braking Resistor
CatNumber
ERN00K7
-
- ERN00K7
ERN01K5
-
ERN02K2
-
ERN04K0
-
ERN05K5
-
ERN07K5
-
ERX00K7
-
ERX01K5
-
ERX02K2
-
ERX04K0
-
ERX05K5
-
ERX07K5
-
-
-
- -
U200ABU430 -
-
U200ABU430
-
U200ABU430
-
-
-
Chapter 6 Peripherals Components
ED% Dim. (mm) CatNumber
10 251*28*60 TLR200P200
10 251*28*60 TLR200P200
10 251*28*60 TLR100P200
10 274*34*78 TLR75P200
10 395*34*78 TLR44P600
10 400*40*100 TLR29P600
10 400*40*100 TLR22P600
10 251*40*20 TLR750P200
10 251*28*60 TLR400P200
10 274*34*78 TLR240P200
10 395*34*78 TLR175P600
10 470*50*100 TLR118P600
10 535*50*110 TLR86P600
- - TLR43P1000
- - TLR43P1000
- - TLR35P1500
- - TLR29P1800
- - TLR22P2500
- - 2xTLR35P1500
- - 2xTLR29P1800
- - 2xTLR22P2500
6-2
GE Tubular Braking Resistor
ED% Dim. (mm)
10% 210*60*65
10% 210*60*65
10% 210*60*65
10% 210*60*65
10% 465*60*95
10% 465*60*95
10% 465*60*95
10% 210*60*65
10% 210*60*65
10% 210*60*65
10% 465*60*95
10% 465*60*95
10% 465*60*95
10% 465*70*100
10% 465*70*100
10% 460*140*100
10% 460*140*100
10% 460*140*180
10% 2x (460*140*100)
10% 2x (460*140*100)
10% 2x (460*140*180)
