◎ Analog comparator
1
2 3
4
5
◎Analog Comparison Mode (1-3)
(1) Analog comparator mode 1
(2) Analog comparator mode 2
(3) Analog comparator mode 3
Selection of the input comparison value (V1-V7)
(1) The input comparison value =V1: Setting Frequency
(2) The input comparison value =V2: Operation Frequency
(3) The input comparison value =V3: AIN Input Value
(4) The input comparison value =V4: AI2 Input Value
(5) The input comparison value =V5: Keypad VR input Value
(6) The input comparison value =V6: Operation Current
(7) The input comparison value =V7: Torque Value
Symbol
Analog comparison mode (1-3)
Selection of the input comparison value
Analog input value
6
Setting reference comparison value (upper limit)
Setting reference comparison value (lower limit)
Output terminals of analog comparator (G1-G4)
≤
( ,
≥
( ,
≤ ≤
(
4-64
Description
ON)
ON)
, ON)
