19. 5-06=23 (Analog input AIN)
The multifunction terminal AIN = 23. The action is provided for setting the frequency.
20. 5-00~06=24 (PLC Application)
The multifunction terminal S1-AIN=24, which means the terminal is for PLC application.
The terminal is provided for the PLC program input.
21. 5-00~06=25 (Traverse Run); 5-00~06=26(Upper Deviation Traverse); 5-00~06=27(Lower
deviation Traverse).
The motion description refers to 3-23~3-29 for detail description.
22. 5-00~06=28 (Power Source Detect for KEB Function)
Please refer to the description of 2-08
Digital /Analog input signal scan times:
5-07: Multifunction terminal S1Ç Ç Ç Ç S6 and AIN signal confirm the scan times (mSec X 4)， ， ， ， 1~100
times
1.TM2 terminal used as scanning, if there are same signals continuously input for N times(Namely, Scan
times), the inverter will treated the signal as normal. During performing the signal, if the scan times
are less than N, the signal will be as noise.
2. Each scan period is 4ms.
3. The user can specify the scan times interval duration according to the noise environment. If the
noise is serious, upper modify the value of 5-07, but the response speed will be slow down.
4. Note: If the S6 and AIN is for digital signal, the voltage level for digital signal above 8V is treated
as ON, below 2V is OFF.
Stop Mode Using MFIT:
5-08:
0000: When Up/Down is used, the preset frequency is hold as the inverter stops, and the UP/Down is
idle.
0001: When Up/Down is used, the preset frequency is reset to 0 Hz as the inverter stops.
0002: When Up/Down is used, the preset frequency is hold as the inverter stops, and the UP/Down is
available.
(1) Set 5-08=0, the inverter will accelerate to the speed of 6-00 as receiving the Run command and
run at such certain speed. The inverter begins to accelerate (decelerate) as the UP (Down) terminal
is energized. The inverter will hold the speed as the UP/DOWN command released. When the Run
Signal releases, the inverter will ramp stop or stop output (determined by the 1-05). It will store the
frequency when the operation signal disappeared. UP/DOWN keys are idle when the inverter is
stop. The keypad is available for you modify the preset frequency (6-00). If 5-08=0002, the
UP/Down is available as the inverter stops.
(2)Set 5-08=1, as the Run terminal is energized, the inverter operates from 0 Hz, the Function of
UP/DOWN is same as the above description. When the Run Signal released, the inverter will
ramp stop or stop output (determined by 1-05) .And back to 0 Hz. The following operation will
always begin from 0 Hz.
