14- Motor Auto-Tune Parameters
Function
LCD
Code No.
Display
14-0
(Stator Resistor)
14-1
(Rotor Resistor)
14-2
(Equi Inductance)
14-3
(Magnet Current)
14-4
(Ferrite Loss)
15- Drive Status and Function Reset
Function
LCD
Code No.
Display
15-0
(Drive Model)
15-1
(Software Version) Software Version
15-2
(Fault Log)
15-3
(Elapsed Hours)
15-4
(Elapsed Hr*10000)
15-5
(Elapsed Time Sel)
15-6
(Reset Parameter)
※ Notes: *1 can be modified during operation
*2 cannot be modified during communication
*3 do not change while making factory setting
*4 as parameter related to factory setting
*5 the parameter will be changed by replacing model (see descriptions of the
POSTSCRIPT 1)
*6 only available in V/F mode
*7 only for version 2.3 and above.
Description
Stator Resistance (Ohms)
Rotor Resistance (Ohms)
Equivalent Inductance (mH)
Magnetizing Current (Amps
AC)
Ferrite Loss Conductance (gm) -----
Description
Drive Horsepower Code
Fault Jog (Last 3 Faults)
Accumulated Operation Time
(Hours)
Accumulated Operation Time
(Hours X 10000)
Accumulated Operation Time
Mode
Reset Drive to Factory Settings
Range/Code
-----
-----
-----
-----
Range/Code
(See page 4-53)
-----
(See page 4-53)
0 - 9999
0 - 27
0000: Time Under Power
0001: Run Mode Time Only
1110: Reset for 50 Hz Motor
Operation
1111: Reset for 60 Hz Motor
Operation
1112: Reset PLC Program
4-19
Chapter 4 Software Index
Factory
Remarks
Setting
*3*5
*3*5
*3*5
*3*5
*3*5
Factory
Remarks
Setting
*3
-----
*3
-----
*3
-----
*3
-----
*3
0000
*3
0000
*4
