GE VAT200 Quick Start Manual page 20

Item
Communication Control
Braking Torque
Operation temperature
Storage temperature
Humidity
Vibration Sustention
EMC
LVD
Enclosure
Safety Level
Overload protection
FUSE protection
Over Voltage
Under Voltage
Momentary Power
Loss Restart
Stall Prevention
Short-circuit output
terminal
Grounding Fault
Other Function
※Note 1：The setting resolution of above 100Hz is 0.1Hz when controlled with operation
keypad, and 0.01 Hz when controlled using computer(PC) or programmable
controller(PLC).
※Note 2：–10 ~ 50℃ in distributor (without dustproof cover),
–10 ~ 40℃outside distributor (with dustproof cover).
VAT200 TYPE
1. Control by RS232 or RS485
2. One to one or One to more (RS485 ONLY) control.
3. BAUD RATE/STOP BIT/PARITY/bit can be set
About 20﹪, the model built-in braking transistor and connected
braking resistor is 100%
-10 ~ 50℃(note 2)
-20 ~ 60℃
0 – 95% Relative Humidity(Non-condense)
2
1G (9.8m/s )
Comply with requirement EN 61800-3 (with optional Filter).
Comply with requirement EN 50178
IP20 ( NEMA 1 by external box attached)
UL 508C
The relays to protect the motor (the curve can be set) and the inverter
(150 % / 1min)
The motor stops after FUSE melt
200V class：DC Voltage＞410V 400V class：DC Voltage＞820V
200V class：DC Voltage＜190V 400V class：DC Voltage＜380V
Stop for more than 15ms-power-loss can be restarted with spin start
after momentary power loss in Max 2 sec.15ms
Stall prevention for Acceleration/ Deceleration/ Operation.
Electronic Circuit Protection
Electronic Circuit Protection
Protection for overheating of heat sink, over torque detection, error
contact control, reverse restriction, restrictions for direct start after
power up and error recovery, parameter lock up.
3-11
Chapter 3 Ambient Environment and Installation
