GE VAT200 Quick Start Manual page 41

※ Notes: Group 7 is available when 5-06=0023 (AIN term.=Analog input
8- Multifunction Output Relays and Output Signal Operation
Function LCD
Code No. Display
8-00 (AO Mode Sel)
8-01 (AO Gain)
8-02 (Relay R1 Sel)
8-03 (Relay R2 Sel)
8-04 (Freq Agree)
8-05 (Freq Agree width)
9- Drive and Load Protection Modes
Function LCD
Code No. Display
9-00 (Trip ACC Sel)
9-01 (Trip ACC Level)
9-02 (Trip DEC Sel)
9-03 (Trip DEC Level)
Description
Analog Output Voltage Mode
(0 - 10 VDC, Term. FM+)
Analog Output Gain (%)
Output Relay R1 Operation
Mode
Output Relay R2 Operation
Mode
Frequency Reached (Hz)
(Refer to 8-02: 0001)
Frequency Reached Bandwidth
(± Hz)
Description
Trip Prevention Selection
During Acceleration
Trip Prevention Level During
Acceleration (%)
Trip Prevention Selection
During Deceleration
Trip Prevention Level During
Deceleration (%)
Range/Code
0000: Output Frequency
0001: Frequency Setting
0002: Output Voltage
0003: DC Voltage
0004: Output Current
0005: PID Feedback *7
0 - 200
0000: Run
0001: Frequency Reached
(Frequency Command) (Set
Frequency ± 8-05)
0002: Set Frequency (8-04 ± 8-05)
0003: Frequency Threshold Level (>
8-04) - Frequency Reached
0004: Frequency Threshold Level (<
8-04) - Frequency Reached
0005: Over torque Threshold Level
0006: Fault
0007: Auto Restart
0008: Momentary AC Power Loss
0009: Rapid Stop Mode
0010: Coast-to-Stop Mode
0011: Motor Overload Protection
0012: Drive Overload Protection
0013: PID Feedback Signal Loss
0014: PLC Operation
0015: Power On *7
0.00 - 650.00
0.00 - 30.00
Range/Code
0000: Enable Trip Prevention During
Acceleration
0001: Disable Trip Prevention
During Acceleration
50 - 300
0000: Enable Trip Prevention During
Deceleration
0001: Disable Trip Prevention
During Deceleration
50 - 300
4-15
Chapter 4 Software Index
)
Factory
Setting
0000
100
0006
0000
0.00
2.00
Factory
Setting
0000
200
0000
200
Remarks
*1
*1
*1
*1
Remarks
