5- Multifunction Input Terminals (MFIT)
Function LCD
Code No. Display
5-00 (MFIT S1 Sel)
5-01 (MFIT S2 Sel)
5-02 (MFIT S3 Sel)
5-03 (MFIT S4 Sel)
5-04 (MFIT S5 Sel)
5-05 (MFIT S6 Sel)
5-06 (MFIT AIN Sel)
5-07 (MFIT Scan Time)
Description
Multifunction Input Term. S1
Multifunction Input Term. S2
Multifunction Input Term. S3
Multifunction Input Term. S4
Multifunction Input Term. S5
Multifunction Input Term. S6
Multifunction Input Term. AIN
Multifunction Input Term. S1 -
S6 Signal Verification Scan
Time (mSec X 4 )
Range/Code
0000: Forward/Stop Command *
0001: Reverse/Stop Command *
0002: Preset Speed # 1 (6-02)
0003: Preset Speed # 2 (6-03)
0004: Preset Speed # 3 (6-05) *
0005: Jog
0006: Acc/Dec # 2
0007: Emergency Stop A Contact
0008: Base Block
0009: Speed Search
0010: Energy Saving
0011: Control Signal Selection
0012: Communication Selection
0013: Acc/Dec Disabled
0014: Up Command
0015: Down Command
0016: Master/Auxiliary Speed
0017: PID Function Disabled
0018: Reset
0019: Encoder input terminal
（ terminal S5 ）
0020: PID feedback signal A12
（ terminal S6 ）
0021: AI2 Bias signal 1 input
（ terminal S6 ）
0022: AI2 Bias signal 2 input
（ terminal S6 ）
0023: Analog input （ terminal AIN ）
0024: PLC Application
0025: Traverse Run
0026: Traverse run upper deviation
0027: traverse run lower deviation
0028: Power Source Detect for KEB
Function
0029: Emergency Stop B Contact *7
1 – 100
4-13
Chapter 4 Software Index
Factory
Remarks
Setting
1
2
0000
3
0001
0002
0003
0004
0018
0023
5
