GE VAT200 Quick Start Manual page 87

Sample:
Input under the Ladder Program Mode
I1 ─ -- ─ -- ─﹝T5
T5 ─ -- ─ -- ─﹝Q1
Input under the Function Program Mode
Timing unit = 0.1 sec
1
Target (setting) value
in timer
(2) Timer Mode 2 (ON-Delay B Mode)
Timer Mode 1
┐ ┐ ┐ ┐
1
│ │ │ │
000.0
│ │ │ │ ─ ─ ─ ─
010.0 T5
┘ ┘ ┘ ┘
Current value
in timer
When I1 = ON, the fifth Timer starts operating
When the time reaches to the target value
10.0 sec, T5 is ON
4-61
Chapter 4 Software Index
