GE VAT200 Quick Start Manual page 2

Step 2 Apply Power to the Drive
Apply AC power to the Drive and observe Operator. Four 7-segment
Display should read Power Voltage for 3~5 seconds and then read
Frequency/Speed, 05.00. Four 7-segment Display and FWD LED should be
flashed all the time.
Step 3 Check Motor Rotation Without Load
Press RUN key (FWD LED should light);
run from 00.00 to 05.00.
Check motor rotation.
If it is not correct:
Press STOP key. Remove AC power. Wait for LED "charge" lamp to extinguish.
Reverse motor leads T1 and T2.Restart the drive and check new rotation.
Press STOP key to stop the drive.
Step 4 Check Full Speed at 50Hz/60Hz
Frequency/Speed
To move right or left for next digit, press SHIFT / RESET key. Press the
READ / ENTER key to set the speed.
Set frequency up to 50Hz/60Hz in accordance with the last rule.
Press RUN key. Check drive acceleration to full speed.
Press STOP key to stop drive and check deceleration.
Step 5 Other Operations
For information, see VAT200 Instruction Manual.
Please refer to the following pages:
Set Accel ......................................................................p. 4-11
Set Decel ..................................................................... p. 4-11
Set Max Speed ............................................................ p. 4-11
Set Min Speed ............................................................. p. 4-11
Set Motor Rated Current ........................................... p. 4-9
Set Control Mode (Vector, V/F) ................................. p. 4-7
can be changed by pressing the up or down Arrow keys.
ii
Four 7-segment Display should
