Page 1 Harmonic MediaGrid Release 4.1 Installation and Configuration Guide Rev C...
Page 2 Harmonic assumes no responsibility or liability arising from the use of the products described herein, except as expressly agreed to in writing by Harmonic. The use and purchase of this product does not convey a license under any patent rights, copyrights, trademark rights, or any intellectual property rights of Harmonic.
Page 3 Commercial Computer Software and Commercial Computer Software Documentation are being licensed to U.S. Government as end users (a) only as Commercial Items and (b) with only those rights as are granted to all other end users pursuant to the terms and conditions herein. Harmonic, 4300 North First Street, San Jose, CA 951 34 U.S.A.
Page 4 CAUTION: The Caution symbol calls your attention to information that, if ignored, can adversely affect the performance of your Harmonic product, or that can make a procedure needlessly difficult. LASER DANGER: The Laser symbol and the Danger alert call your attention to information about the lasers in this product that, if ignored, can cause physical harm to you.
Page 5: Table Of Contents
About a Harmonic MediaGrid Stretch Cluster ....... . . 20...
Page 6 Connecting the Power Cables in a System with ContentServer 4000 Series ..65 Expanding a Harmonic MediaGrid 4000 Series System ......66 Chapter 3: System Installation with the ContentServer 3000 Series ..68...
Page 7 Setting the Harmonic MediaGrid System Time ........
Page 8 Settings for OS X 10.9.5 or Later With Certain NICs ......168 Installing the Harmonic MediaGrid File System Driver for Linux ....168 Verifying the Kernel Version .
Page 9 Chapter 6: Accessing the Harmonic MediaGrid........171 About Accessing a Harmonic MediaGrid System ....... . 171 Mounting a Harmonic MediaGrid File System Using Windows .
Page 10 Powering Down a Harmonic MediaGrid System ....... . . 213...
Page 11 Troubleshooting on the ContentBridge ........285 ContentBridge Mounts to the Harmonic MediaGrid ......285 ContentBridge Configuration Files .
Page 12 Monitoring via Log Files ..........332 Appendix A: Contacting the Technical Assistance Center .......334 Appendix B: Safety and Regulatory Compliance Information ....336 © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 13: Introduction
Introduction Congratulations on choosing a Harmonic MediaGrid system. This guide provides information on how to install and configure a Harmonic MediaGrid system. Choose from the following sections: “Introduction” (this section) gives an overview of the Harmonic MediaGrid Documentation  Suite and lists terms and conventions.
Page 14: Locating The Latest Documentation On The Harmonic Web Site
The ContentBridge is an optional device that provides standard interfaces to the Harmonic  MediaGrid for clients that do not have the Harmonic MediaGrid File System Driver (FSD) installed, or where an FSD is not available. The supported protocols are CIFS, FTP, and NFS.
Page 15 FTP (File Transfer Protocol) is an interface used by a computer user to exchange files  between computers. Refer to ContentBridge. Group refers to a collection of one or more ContentServers in a Harmonic MediaGrid.  NFS (Network File System) is a protocol that allows access to files from a client computer ...
Page 16: Chapter 1: System Overview And Requirements
Harmonic MediaGrid is a powerful disk storage server system specifically designed with the needs of large file storage and access in mind. Harmonic MediaGrid boasts unique capabilities to meet the most demanding capacity, performance and data availability requirements. The software RAID implementation is tightly integrated into the File System delivering high performance and fast RAID rebuilds.
Page 17: Contentdirector
Harmonic representative. IMPORTANT: The ContentServer 3000/4000 series cannot be connected directly to CX4 ports. If you are supplying a switch for a Harmonic MediaGrid system with the ContentServer 3000 or 4000, the following switch functionality is required: Full wire-speed, non-blocking architecture ...
Page 18: Contentbridge
The ContentBridge is an optional server that provides access to Harmonic MediaGrid for client platforms that do not have the File System Driver (FSD) installed or do not use the Harmonic MediaGrid API. The ContentBridge also supports active files transfers. This server provides a...
Page 19: About Naming Files And System Elements
Omnibus side. To create clips for use on an Omnibus system, follow these guidelines: Avoid creating long Harmonic clip names that only differ in the last few characters as long  Harmonic clip names are truncated to 25 characters when Omnibus clip names are generated.
Page 20: About Clusters, Volumes And Groups
Harmonic MediaGrid supports using replication on systems with the ContentServer 3000 Series. This feature provides an additional level of data protection by allowing you to set up a Harmonic MediaGrid system across two different sites and replicate data across sites. This configuration is known as a “stretch cluster.
Page 21: Supported Raid Configurations
Uplink (typically 10 GbE) BMC Connection Site 2 Site 1 Figure 1–1: Harmonic MediaGrid Stretch Cluster Supported RAID Configurations Understand the difference between “capacity optimized” and “performance optimized” RAID configurations, and which configurations are supported in each ContentServer and ContentStore model.
Page 23: About Drive Replacement
Before installing your Harmonic MediaGrid system, you must allocate an IP address range for the Harmonic MediaGrid Public VLAN. The Public VLAN is an IP subnet, which will be visible by all parts of the network that access the Harmonic MediaGrid. Make sure the Public VLAN is dedicated to Harmonic MediaGrid components, and accessible by clients that will access the Harmonic MediaGrid.
Page 24: Private Vlans
Network Configuration Private VLANs Before installing your Harmonic MediaGrid system, you must also allocate IP address ranges for two Private VLANs. The Private VLANs are private IP subnets that create redundant paths between the ContentDirectors, allowing them to communicate information and keeping them synchronized.
Page 25: Network Diagram With 10 Gbe Network
ContentServer to the 1 GbE switch. The BMC cables should be connected to the Public VLAN. ContentStores are connected to a ContentServer via SAS cables.  © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 26 Uplink (typically 10 GbE) BMC Connection (on Public VLAN) ContentStores ContentStores ContentStores Figure 1–3: Harmonic MediaGrid System with 10 GbE Network Figure 1–3, note the following: The blue cables and the gray cables represent different connections on the same Public  VLAN.
Page 27: Network Diagram With 1 Gbe Network
ContentServer to the 1 GbE switch. This connection can be used for data transfer in addition to the BMC. The BMC cables should be connected to the Public VLAN. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 28 (on Public VLAN) ContentStores ContentStores ContentStores ContentStores Figure 1–4: Harmonic MediaGrid System with ContentServer 3000 Series and 1 GbE Network Figure 1–4, note the following: The blue cables and the gray cables represent different connections on the same Public ...
Page 29: Required Information For A Windows Domain Controller
A domain controller server, which manages access to resources within a Windows domain, is required at the installation site. Harmonic MediaGrid must be “joined” to the site’s Windows domain for user authentication and security when clients attempt to access Harmonic MediaGrid file systems.
Page 30 ActiveDirectory Realm  ActiveDirectory Workgroup  ActiveDirectory server Hostname  ActiveDirectory server FQDN (Fully Qualified Domain Name)  ActiveDirectory server IP address  ActiveDirectory server Administrator Username and Password  © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 31: Chapter 2: System Installation With The Contentserver 4000 Series
Site  Harmonic MediaGrid equipment is designed for rack mounting. Be sure to read racking precautions before you begin unpacking system components. Be aware of the weight of the ContentServers and ContentStores so that you may safely move and lift devices.
Page 32: Required Components
Harmonic representative immediately. Cables and Mounting Hardware A rack mounting kit is provided with each Harmonic MediaGrid component, which provides the items needed to mount each component on a rack. Mounting instructions are also included. The type, quantity and length of the cables depends on the customer site and will likely differ for each separate installation.
Page 33: Racking Precautions
Racking Precautions for the ContentStore 5840. Safe handling of this system requires at least TWO people. Harmonic recommends that you  use THREE people to rack mount a system; two to lift and one to help guide the system onto the rack rails.
Page 34 Chapter 2 System Installation with the Content- Racking Precautions Server 4000 Series IMPORTANT: Use only the power cables provided by Harmonic. IMPORTANT: The ContentServer and ContentStore 4000 series must be connected to reliable grounding before applying power. IMPORTANT: The ContentServer and ContentStore 4000 series will not receive sufficient airflow or cooling if it is operated with any of the front or rear modules missing.
Page 35: Rack Mounting The Harmonic Mediagrid 4000 Series System
Chapter 2 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 4000 Series System Server 4000 Series Rack Mounting the Harmonic MediaGrid 4000 Series System A rack mounting kit is provided with each device, which includes the necessary hardware along with detailed mounting instructions.
Page 36 Chapter 2 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 4000 Series System Server 4000 Series Repeat Step a through Step e to install the other inner rail. 2. On each outer rail, press the locking tab and push the middle rail toward the back of the rail to collapse the rail assembly.
Page 37 Chapter 2 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 4000 Series System Server 4000 Series Step a Step c d. Repeat through to install the back end of the rail, extending the rail as needed. 4. Repeat Step 3 to install the right outer rail.
Page 38 Chapter 2 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 4000 Series System Server 4000 Series b. Fully extend the middle rails, making sure that the ball bearing shuttle is locked at the front of each middle rail.
Page 39 Chapter 2 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 4000 Series System Server 4000 Series The drive tray is in the correct position when its front edge lines up with the edge of the drive bay. 3. Close the drive carrier lever to lock the drive into place.
Page 40: Rack Mounting The Contentstore 5840
Drawer. Additionally, you may wish to remove other modules from the chassis before lifting. For  component removal and installation instructions, see the Harmonic MediaGrid Component Replacement Guide. Note the following important points on handling: It is recommended that a minimum of three people lift the ContentStore 5840 using the lifting ...
Page 41 Chapter 2 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 4000 Series System Server 4000 Series Rack System Safety CAUTION: The ContentStore 5840 must only be mounted into a rack using the supplied rail kit. Due to its weight and length, the ContentStore 5840 must not be flange mounted.
Page 42 Chapter 2 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 4000 Series System Server 4000 Series IMPORTANT: The ContentStore 5840 must be grounded before applying power. The plug on the power supply cord is used as the main disconnect device. Ensure that the socket outlets are located near the equipment and are easily accessible.
Page 43 Chapter 2 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 4000 Series System Server 4000 Series Site Requirements Before you begin, make sure the site where you intend to set up and use your storage system has the following: Standard power from an independent source or a rack power distribution unit with a UPS.
Page 44 Chapter 2 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 4000 Series System Server 4000 Series Figure 2–2: Mounting the System into a Rack (left hand rail only shown for clarity) 4. Fully tighten all clamping screws and middle slide-locking screws.
Page 45 Chapter 2 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 4000 Series System Server 4000 Series Figure 2–3: Rear Enclosure Mounting CAUTION: Use only the power cords supplied. CAUTION: Once the enclosure is installed in the rack, dispose of the lifting straps. Due to the difficulty in attaching the straps once the enclosure is installed in the rack, the straps are not suitable for removing the enclosure from the rack.
Page 46 Chapter 2 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 4000 Series System Server 4000 Series To open a drawer: 1. Make sure the anti-tamper locks are not engaged. The red arrows on the locks will point Figure 2–4).
Page 47 Chapter 2 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 4000 Series System Server 4000 Series To close a drawer: 1. Pull and hold both of the white latches on the sides of the drawer (see Figure 2–6).
Page 48: Rack Mounting The Contentdirector 1000F/2000C And Contentbridge 2010F
Chapter 2 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 4000 Series System Server 4000 Series Figure 2–7: Drive install Figure 2–8. 4. Check that the release latch has returned to its locked position, as shown in Figure 2–8: Drive locked 5.
Page 49 Chapter 2 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 4000 Series System Server 4000 Series NOTE: The figures in this section show a two-rack unit server; however, the same rack rails are used for the ContentDirector 1000F/2000C and ContentBridge 2010F.
Page 50 Chapter 2 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 4000 Series System Server 4000 Series d. Move the ball retainer to the front of the rack. 3. Install the inner member (component D) to the chassis as follows: Align inner member key holes to the standoffs on the chassis.
Page 51: Rack Mounting The Network Switches
6. Install the bottom-most screw at the front to secure the chassis to the rack. Installing the bezel on the ContentDirector 1000F/2000C and ContentBridge 2010F Align the bezel in front of the chassis so that the Harmonic logo is positioned in the top left corner.
Page 52: Connecting The Harmonic Mediagrid 4000 System Components
Other colors can be used instead as long as the connections correspond to the blue, white, and red network cables shown in this section. Connecting System Components: Overview 1. Connect Harmonic MediaGrid system components to the network switches in the following order: ContentDirectors Connecting ContentDirectors to the Network Switch.
Page 53 IMPORTANT: Make sure to use only Harmonic MediaGrid-qualified switches in your Harmonic MediaGrid system. To find out if a switch is Harmonic MediaGrid-qualified, contact your Harmonic representative. NOTE: The switches shown in this section are example only. Your switch may vary from those shown.
Page 54 Module A Module B Module D Module C First ContentDirector SystemManager Gb 1 Gb 2 First ContentServer ContentBridge 2010F (Optional) Figure 2–15: Harmonic MediaGrid 4000 Series and Network Switch Connections © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 55: Connecting Contentdirectors To The Network Switch
BMC port on each controller on a ContentServer to the network switch. Connecting ContentDirectors to the Network Switch Follow these instructions for single-site Harmonic MediaGrid systems. IMPORTANT: Ports 1-4 on switch modules C and D are reserved for ContentDirector private interface (ports 2 and 3) connections only.
Page 56: Connecting The Systemmanager To The Network Switch
Harmonic SystemManager Installation Guide. IMPORTANT: vDHCP must be disabled in the SystemManager application before connecting the SystemManager device to the 1 GbE network switch. Refer to “Disabling vDHCP” in the Harmonic SystemManager User Guide for instructions.
Page 57 Chapter 2 System Installation with the Content- Connecting the Harmonic MediaGrid 4000 System Components Server 4000 Series IMPORTANT: To ensure redundancy and proper failover in the event of a failure, you must connect each controller to a separate switch or switch module.
Page 58: Connecting The Contentserver 4000 To The Network Switch (Lower Ports)
Chapter 2 System Installation with the Content- Connecting the Harmonic MediaGrid 4000 System Components Server 4000 Series Connecting the ContentServer 4000 to the Network Switch (lower ports) 1. Starting with Controller A, connect a red CAT-6 Ethernet cable to the BMC port (maximum data rate 100Mb/s).
Page 59: Connecting The High Bandwidth Contentbridge To The Network Switch
ContentBridge, then connect the other end of the cable to an available port on the customer core switch. 3. Connect the customer core switch to the Harmonic MediaGrid network switches. Refer to Connecting Network Switches to the Client Network: One-rack System...
Page 60: Connecting High Bandwidth Contentbridges In A High Availability Pair
5. Connect a 1 GbE cable to the right-hand NIC (Eth 1) on the first ContentBridge, then connect the other end of the cable to the right-hand NIC (Eth 1) on the second ContentBridge. 6. Connect the customer core switch to the Harmonic MediaGrid network switches. Refer to Connecting Network Switches to the Client Network: One-rack System...
Page 61: Connecting The Contentserver 4000 To The Contentstore 4240
Chapter 2 System Installation with the Content- Connecting the Harmonic MediaGrid 4000 System Components Server 4000 Series To Harmonic MediaGrid Network Customer Core Switch ContentBridge 2010F ContentBridge 2010F Figure 2–21: High Bandwidth ContentBridges connected in an HA pair to the network switch Connecting the ContentServer 4000 to the ContentStore 4240 You can connect up to four ContentStore 4240 storage arrays to a single ContentServer 4000.
Page 62: Connecting The Contentserver 4000 To The Contentstore 5840
Figure 2–22: Connecting the ContentServer 4000 to the ContentStore 4240 Connecting the ContentServer 4000 to the ContentStore 5840 At this time, Harmonic supports connecting a single ContentStore 5840 to a ContentServer 4000. NOTE: When connecting the ContentServer to the ContentStore, be careful to not twist the SAS cables, bundle them with power cables, or inadvertently braid the cables together.
Page 63: Connecting Network Switches To The Client Network: One-Rack System
Figure 2–23: Connecting the ContentServer 4000 to the ContentStore 5840 Connecting Network Switches to the Client Network: One-rack System This section provides instructions for connecting the network switches in a one-rack Harmonic MediaGrid system to the client network. Refer to...
Page 64: Connecting Network Switches To The Client Network: Two-Rack System
Your switches may vary from the ones shown. IMPORTANT: Make sure to use only Harmonic MediaGrid-qualified switches in your Harmonic MediaGrid system. To find out if a switch is Harmonic MediaGrid-qualified, contact your Harmonic representative. To Client Network First Switch Second Switch Figure 2–24: Network Switches and Client Network Connections...
Page 65: Connecting The Power Cables In A System With Contentserver 4000 Series
Chapter 2 System Installation with the Content- Connecting the Harmonic MediaGrid 4000 System Components Server 4000 Series To Client Network To Client Network 10GbE Switch 10GbE Switch First Switch First Switch Second Switch Second Switch Rack One Rack Two Figure 2–25: Network Switches and Client Network Connections Connecting Components in Rack One 1.
Page 66: Expanding A Harmonic Mediagrid 4000 Series System
Expanding a Harmonic MediaGrid 4000 Series System Follow this procedure when you wish to connect an additional ContentStore to an existing Harmonic MediaGrid system while the system is powered on. You can connect up to four ContentStore 4240 nodes to the ContentServer 4000.
Page 67 Chapter 2 System Installation with the Content- Expanding a Harmonic MediaGrid 4000 Series System Server 4000 Series ContentServer Properties Status 7. On the page in SystemManager, verify that the field for Connected Controller 0 changes to Shutdown 8. Power down the bottom controller by clicking the...
Page 68: Chapter 3: System Installation With The Contentserver 3000 Series
Site  Harmonic MediaGrid equipment is designed for rack mounting. Be sure to read racking precautions before you begin unpacking system components. Be aware of the weight of the ContentServers and ContentStores so that you may safely move and lift devices.
Page 69: Shipping Container Components
Harmonic representative immediately. Cables and Mounting Hardware A rack mounting kit is provided with each Harmonic MediaGrid component, which provides the items needed to mount each component on a rack. Mounting instructions are also included. The type, quantity and length of the cables depends on the customer site and will likely differ for each separate installation.
Page 70: Racking Precautions
IMPORTANT: For precautions specific to the ContentStore 5840, see Rack Mounting the ContentStore 5840. Safe handling of this system requires at least TWO people. Harmonic recommends that you  use THREE people to rack mount a system; two to lift and one to help guide the system onto the rack rails.
Page 71 Chapter 3 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 3000 Series System Server 3000 Series d. Secure the chassis to the rails with screws. e. Repeat steps 1-3 for the other inner rail. Figure 3–1: Installing the inner rack rails 3.
Page 72: Installing The Bezel
Chapter 3 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 3000 Series System Server 3000 Series b. With two people holding the chassis level and a third guiding the chassis, line up the inner (chassis) rails with the front of the outer (rack) rails so that the chassis is square with the rack rails.
Page 73: Rack Mounting The Contentstore 5840
For details, see Additionally, you may wish to remove other modules from the chassis before lifting. For  component removal and installation instructions, see the Harmonic MediaGrid Component Replacement Guide. Note the following important points on handling: It is recommended that a minimum of three people lift the ContentStore 5840 using the lifting ...
Page 74 Chapter 3 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 3000 Series System Server 3000 Series Rack System Safety CAUTION: The ContentStore 5840 must only be mounted into a rack using the supplied rail kit. Due to its weight and length, the ContentStore 5840 must not be flange mounted.
Page 75 Chapter 3 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 3000 Series System Server 3000 Series IMPORTANT: The ContentStore 5840 must be grounded before applying power. The plug on the power supply cord is used as the main disconnect device. Ensure that the socket outlets are located near the equipment and are easily accessible.
Page 76 Chapter 3 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 3000 Series System Server 3000 Series Site Requirements Before you begin, make sure the site where you intend to set up and use your storage system has the following: Standard power from an independent source or a rack power distribution unit with a UPS.
Page 77 Chapter 3 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 3000 Series System Server 3000 Series Figure 3–5: Mounting the System into a Rack (left hand rail only shown for clarity) 4. Fully tighten all clamping screws and middle slide-locking screws.
Page 78 Chapter 3 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 3000 Series System Server 3000 Series Figure 3–6: Rear Enclosure Mounting CAUTION: Use only the power cords supplied. CAUTION: Once the enclosure is installed in the rack, dispose of the lifting straps. Due to the difficulty in attaching the straps once the enclosure is installed in the rack, the straps are not suitable for removing the enclosure from the rack.
Page 79 Chapter 3 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 3000 Series System Server 3000 Series To open a drawer: 1. Make sure the anti-tamper locks are not engaged. The red arrows on the locks will point Figure 3–7).
Page 80 Chapter 3 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 3000 Series System Server 3000 Series To close a drawer: 1. Pull and hold both of the white latches on the sides of the drawer (see Figure 3–9).
Page 81 Chapter 3 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 3000 Series System Server 3000 Series Figure 3–10: Drive install 4. Check that the release latch has returned to its locked position, as shown in Figure 3–11. Figure 3–11: Drive locked 5.
Page 82: Rack Mounting The Contentdirector 1000F/2000C And Contentbridge 2010F
Chapter 3 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 3000 Series System Server 3000 Series Rack Mounting the ContentDirector 1000F/2000C and ContentBridge 2010F The ContentDirector 1000F/2000C and ContentBridge 2010F (an optional system component) ship with the Intel AXXVRAIL Mounting Rail Kit.
Page 83 Chapter 3 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 3000 Series System Server 3000 Series Figure 3–13: Fastening slides to front rack posts d. Move the ball retainer to the front of the rack. 3. Install the inner member (component D) to the chassis as follows: Align inner member key holes to the standoffs on the chassis.
Page 84 6. Install the bottom-most screw at the front to secure the chassis to the rack. Installing the bezel on the ContentDirector 1000F/2000C and ContentBridge 2010F Align the bezel in front of the chassis so that the Harmonic logo is positioned in the top left corner.
Page 85: Rack Mounting The Network Switches
Chapter 3 System Installation with the Content- Rack Mounting the Harmonic MediaGrid 3000 Series System Server 3000 Series Backside View of Bezel Captive Fastener Figure 3–16: Installing the bezel on the ContentDirector 1000F/2000C and ContentBridge 2010F Rack Mounting the Network Switches NOTE: The network switches are not deep enough to be attached to the front rails.
Page 86: Connecting The Harmonic Mediagrid 3000 System Components
5. Repeat the previous steps to install the remaining network switches. Refer to the network switch product manuals provided with the Harmonic MediaGrid system for more information about rack mounting the switches. Connecting the Harmonic MediaGrid 3000 System Components The following section provides instructions for connecting the Harmonic MediaGrid storage system components.
Page 87 IMPORTANT: Make sure to use only Harmonic MediaGrid-qualified switches in your Harmonic MediaGrid system. To find out if a switch is Harmonic MediaGrid-qualified, contact your Harmonic representative. NOTE: The switches shown in this section are example only. Your switch may vary from those shown.
Page 88 Module A Module B Module D Module C First ContentDirector First ContentServer SystemManager Gb 1 Gb 2 ContentBridge 2010F (Optional) Figure 3–18: Harmonic MediaGrid and 10 GbE Network Switch Connections © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 89 Module A Module B Module D Module C First ContentDirector First ContentServer SystemManager Gb 1 Gb 2 ContentBridge 1000B (Optional) Figure 3–19: Harmonic MediaGrid and 1 GbE Network Switch Connections © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 90: About Bmc Connectivity
1 GbE connection from NIC 0 on each controller on a ContentServer to the network switch. Connecting the ContentDirectors to a Network Switch Follow these instructions for single-site Harmonic MediaGrid systems. If you are configuring a stretch cluster, follow instructions in Connecting ContentDirectors in a Stretch Cluster instead.
Page 91 Chapter 3 System Installation with the Content- Connecting the Harmonic MediaGrid 3000 System Components Server 3000 Series Figure 3–21 shows a detail of the ContentDirector connections to network switches across two sites. 10-GbE SFP+ Ports 10-GbE SFP+ Ports 10-GbE SFP+ Ports...
Page 92: Connecting The Systemmanager To The Network Switch
Harmonic SystemManager Installation Guide. IMPORTANT: vDHCP must be disabled in the SystemManager application before connecting the SystemManager device to the 1 GbE network switch. Refer to “Disabling vDHCP” in the Harmonic SystemManager User Guide for instructions.
Page 93 Chapter 3 System Installation with the Content- Connecting the Harmonic MediaGrid 3000 System Components Server 3000 Series 10-GbE SFP+ Ports SFP+ Ports 10-GbE SFP+ Ports 1 GbE Module A 1 GbE Module B Controller A Controller B Figure 3–23: ContentServer 3000 and 1 GbE Network Switch Connections To connect the ContentServer to a network switch: 1.
Page 94 Chapter 3 System Installation with the Content- Connecting the Harmonic MediaGrid 3000 System Components Server 3000 Series IMPORTANT: To ensure redundancy and proper failover in the event of a failure, you must connect each controller to a separate switch or switch module.
Page 95: Connecting The High Bandwidth Contentbridge To The Network Switch
ContentBridge, then connect the other end of the cable to an available port on the customer core switch. 3. Connect the customer core switch to the Harmonic MediaGrid network switches. Refer to Connecting Network Switches to the Client Network: One-rack System...
Page 96: Connecting High Bandwidth Contentbridges In A High Availability (Ha) Pair
5. Connect a 1 GbE cable to the right-hand NIC (Eth 1) on the first ContentBridge, then connect the other end of the cable to the right-hand NIC (Eth 1) on the second ContentBridge. 6. Connect the customer core switch to the Harmonic MediaGrid network switches. Refer to Connecting Network Switches to the Client Network: One-rack System...
Page 97: Connecting The Contentbridge 1000B To The Network Switch
Figure 3–26: High Bandwidth ContentBridges connected in an HA pair to the network switch Connecting the ContentBridge 1000B to the Network Switch 1. Complete these connections if one or more optional ContentBridges are part of the Harmonic MediaGrid system. Connect port 1 on the first ContentBridge to the first available port on switch module C.
Page 98 Chapter 3 System Installation with the Content- Connecting the Harmonic MediaGrid 3000 System Components Server 3000 Series ContentServer ContentStore ContentStore Figure 3–27: Connecting the ContentServer 3000 to ContentStores 3160 To connect the ContentServer to multiple ContentStores: 1. Starting with the left-hand controller on the ContentServer, connect a SAS cable to the SAS port.
Page 99: Connecting The Contentserver 3000 To The Contentstore 5840
NOTE: A maximum of five ContentStores can be connected to one ContentServer. Connecting the ContentServer 3000 to the ContentStore 5840 At this time, Harmonic supports connecting no more than one ContentStore 5840 to a ContentServer 3000. Use the following instructions and Figure 3–28...
Page 100: Connecting Network Switches To The Client Network: One-Rack System
IMPORTANT: If you are supplying your own network switches, make sure to use only Harmonic MediaGrid-qualified switches in your Harmonic MediaGrid system. To find out if a switch is Harmonic MediaGrid-qualified, contact your Harmonic representative. To Client Network...
Page 101: Connecting The Power Cables In A System With Contentserver 3000 Series
Server 3000 Series IMPORTANT: If you are supplying your own network switches, make sure to use only Harmonic MediaGrid-qualified switches in your Harmonic MediaGrid system. To find out if a switch is Harmonic MediaGrid-qualified, contact your Harmonic representative. To Client Network...
Page 102: Expanding A Harmonic Mediagrid 3000 Series System
Expanding a Harmonic MediaGrid 3000 Series System Follow this procedure when you wish to connect an additional ContentStore to an existing Harmonic MediaGrid while the system is powered on. You can connect up to five ContentStore 3160 nodes to the ContentServer 3000.
Page 103 Chapter 3 System Installation with the Content- Expanding a Harmonic MediaGrid 3000 Series System Server 3000 Series Properties ContentServer Controllers From the page, scroll to the section and then click Shutdown button for Controller 0. d. Click to confirm. 4. Connect one end of the SAS cable to the right-hand SAS port on the left-hand controller on the last ContentStore in the daisy chain, and then connect the other end of the cable to the left-hand SAS port on the left-hand controller on the new ContentStore.
Page 104: Chapter 4: System Configuration
Configuring a ContentServer  NOTE: Many of the Harmonic MediaGrid system configuration options covered in this chapter are applied by editing configuration files using the SystemManager application. You are directed to the Harmonic SystemManager User Guide for complete instructions when customizing these configuration files.
Page 105: Configuring The Network Switches
Configuring the Network Switches Before configuring your Harmonic MediaGrid system, you must configure your network switches. If you are using 1GbE switches provided by Harmonic for an all-1GbE network, you can use the Network Configuration Assistant, a stand-alone utility, described in this section.
Page 106: Uploading Switch Configuration Files
Chapter 4 System Configuration Configuring the Network Switches Use the information from the Harmonic MediaGrid Installation Planning Guide to complete the assistant. When complete, the switch configuration files will be copied to the USB drive and generated under the following directory: /home/ovnuser/scripts/legacy/configfiles...
Page 107: Getting Started With The Harmonic Mediagrid Configuration Assistant
Chapter 4 System Configuration Getting Started with the Harmonic MediaGrid Configuration Assistant For the CX4 1 0GbE connections (both four and eight) on the top row of the switch, use  the HP5400_CX4.cfg file For the fiber 1 0GbE connections (both four and eight) on the top row of the switch, use ...
Page 108: Powering On A Harmonic Mediagrid System
Cluster. This will help you select the RAID set geometry that best serves your needs. Powering on a Harmonic MediaGrid System Make sure all of the Harmonic MediaGrid devices are connected before continuing. Refer to Connecting the Harmonic MediaGrid 4000 System Components Connecting the Harmonic MediaGrid 3000 System Components for instructions.
Page 109: Running The Configuration Assistant
MediaGrid Configuration Assistant before continuing. To run the configuration assistant: 1. Connect a monitor and keyboard to the first ContentDirector in your Harmonic MediaGrid system. CAUTION: Do not attempt to run the Configuration Assistant remotely (for example, via SSH). You must run the Configuration Assistant directly from the ContentDirector in order for it to successfully configure the system.
Page 110  3. Run the discover command to verify that the configuration assistant will be able to detect all of the devices in your Harmonic MediaGrid system. Enter the following: sudo discover -c Depending on the number of devices in your system, this process may take up to 10 minutes Figure 4–1.
Page 111: Verifying Startup Processes
If you wish to join a ContentBridge 1000B to an Active Directory domain, you must do so  when configuring the Harmonic MediaGrid system with the configuration assistant. The High Bandwidth ContentBridge can be joined to an Active Directory domain either while...
Page 112: Initializing Clusters
1. Make sure that the ContentServers have been acquired by typing the following: sudo /opt/omcld/bin/ssmdiag -s You should output similar to the following: SSID=0 SN=S00007E6A1.0 MGRAID3000 10.4.252.12 10.4.252.15 GB=253/ 9264 SC=47229 © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 113: Setting The Harmonic Mediagrid System Time
NOTE: The procedure described in this section can only performed after you have run the Configuration Assistant. Harmonic MediaGrid requires a common time reference for all of its components, which is important for file stamps and log messages. Complete the following process to set the system time and to synchronize the components.
Page 114: Creating A Raid Set
Once the system is installed and configured, create a Volume and then organize the ContentServers into Groups. Use the SystemManager application to create the Volume and Groups. See “Creating or Deleting Volumes” and “Creating or Deleting Groups” in the Harmonic SystemManager User Guide for instructions on organizing the ContentServers.
Page 115: Configuring For Active Directory
Chapter 4 System Configuration Joining a Harmonic MediaGrid Cluster to a Windows Domain Configuring for Active Directory Complete the following procedures to use the standard method of Active Directory authentication. The Active Directory Domain name must be a Fully Qualified Domain Name (FQDN), which is a domain name containing three or four parts, (for example, “ahost.example.com”).
Page 116 Workgroup and realm entries are needed to specify the Windows NT Domain name and the active Directory Domain name in the smb.conf file. For example, if the Windows NT domain name is Harmonic.local, then the realm is Harmonic. To add a workgroup and realm entry: 1.
Page 117 Required Information for a Windows Domain Controller In addition to the following, refer to for a complete list of expected customer-provided information to join Harmonic MediaGrid to a Windows domain. You will need the following before beginning: © 2017 Harmonic Inc. All rights reserved.
Page 118 Chapter 4 System Configuration Joining a Harmonic MediaGrid Cluster to a Windows Domain Administrator privileges to complete the following steps. Contact the system administrator for  site-specific information, including user names, domain names and passwords. The “Windows NT domain name” from the facility’s network domain administrator.
Page 119: About Joining A High Bandwidth Contentbridge To An Active Directory Domain
Chapter 4 System Configuration Joining a Harmonic MediaGrid Cluster to a Windows Domain ContentDirector Properties NOTE: SystemManager provides winbind status (running or not) on the page. See the Harmonic SystemManager User Guide for details. Verifying Communication with the Domain Controller 1.
Page 120 Chapter 4 System Configuration Joining a Harmonic MediaGrid Cluster to a Windows Domain Make sure you have reviewed the Harmonic MediaGrid Installation Planning Guide and have  a completed copy of the configuration worksheet included in that document on hand.
Page 121 “CB” in this file). Restart gateway services by running the following command: sudo service gateway restart NOTE: In order to access the Harmonic MediaGrid, the individual users must be added to the Active Directory domain. About Changes to the Default Mount Point...
Page 122: Method
At the prompt, you will be able to list the file system, and perform other operations. NOTE: Make sure the Harmonic MediaGrid cluster is also configured with Active Directory. NOTE: In order to access the Harmonic MediaGrid, the individual users must be added to the Active Directory domain.
Page 123 (the entries do not contain “CB” in this file). NOTE: In order to access the Harmonic MediaGrid, the individual users must be added to the Active Directory domain. 3. Restart the gateway service. For example, for a High Bandwidth ContentBridge with hostname...
Page 124: Joining A Contentbridge 1000B To An Active Directory Domain Using The Manual Method
Follow the steps described in NOTE: Make sure the Harmonic MediaGrid cluster is also configured with Active Directory. NOTE: In order to access the Harmonic MediaGrid, the individual users must be added to the Active Directory domain. Joining a ContentBridge 1000B to an Active Directory Domain Using the...
Page 125 Chapter 4 System Configuration Joining a Harmonic MediaGrid Cluster to a Windows Domain This is the main Samba configuration file. You should read # smb.conf(5) manual page in order to understand the options listed # here. Samba has a huge number of configurable options...
Page 126 Chapter 4 System Configuration Joining a Harmonic MediaGrid Cluster to a Windows Domain Replace <ADS Domain Controller FQDN> with the Fully Qualified Domain Name of the ActiveDirectory server. /tftpboot/config/gateway/krb5.conf 4. Generate the file, , as shown in Figure 4–3. [logging] default = FILE:/var/log/krb5libs.log...
Page 127 (the entries do not contain “CB” in this file). NOTE: In order to access the Harmonic MediaGrid, the individual users must be added to the Active Directory domain. 7. Add the following line to the ContentBridge 1000B configuration file: NATIVE <Cluster IP or DNS name>...
Page 128: Adding The Harmonic Mediagrid Devices To The Local Dns
An entry for each of the Harmonic MediaGrid devices below must be added to the customer’s DNS for client access of the Harmonic MediaGrid system. This will result in the DNS providing a round-robin allocation of the IP addresses when requested.
Page 129: Setting Up Reverse Dns Lookups
DNS entries. Setting up Reverse DNS Lookups Follow these steps to configure reverse DNS entries for Harmonic MediaGrid devices on a Microsoft Windows-based DNS server. For other types of DNS servers, consult the appropriate documentation or Network Administrator to set up reverse DNS entries.
Page 130: Joining A Harmonic Mediagrid Cluster To A Lightweight Directory Access Protocol (Ldap)
Chapter 4 System Configuration Joining a Harmonic MediaGrid Cluster to a Lightweight Directory Access Protocol (LDAP) Domain It is not recommended that you switch between ADS and LDAP once an authentication method is chosen. Doing so requires resetting all Access Control Lists (ACLs), as the Security Identifiers (SIDs) differ between the two methods.
Page 131: Tracing An Ldap Problem
Chapter 4 System Configuration Joining a Harmonic MediaGrid Cluster to a Lightweight Directory Access Protocol (LDAP) Domain If you see the following output, LDAP is not configured properly, and you must trace the problem: id: admin: No such user 6. Restart the omcld service by typing the following:...
Page 132 [root@eng-ldap ~]# /var/lib/samba/sbin/smbldap-usershow hbcb205$ NOTE: Configuring different ContentBridges in a Harmonic MediaGrid cluster with different directory access authentication protocols (for example, ADS, LDAP, and OpenDirectory) is not supported. The following set of steps will reset the authentication mechanism for all ContentBridges in the cluster.
Page 133: Joining A Contentbridge 1000B To An Ldap Domain
Verifying Communication with the Domain Controller. NOTE: Make sure the Harmonic MediaGrid cluster is also configured with LDAP. NOTE: In order to access the Harmonic MediaGrid, the individual users must be added to the LDAP domain. Joining a ContentBridge 1000B to an LDAP Domain Follow the procedures in this section in order.
Page 134 (the entries do not contain “CB” in this file). NOTE: In order to access the Harmonic MediaGrid, the individual users must be added to the LDAP domain. 7. Add the following line to the ContentBridge configuration file. This can be done via SystemManager or by editing /tftpboot/config/gateway/<hostname>...
Page 135: Joining A Harmonic Mediagrid Cluster To An Apple Open Directory Domain
Domain Harmonic MediaGrid supports Apple Open Directory for authentication and directory services. If you have enabled LDAP Bind Authentication on your Mac OS X server, you can join the Harmonic MediaGrid to Apple Open Directory. IMPORTANT: As of OS X Server 10.7, Apple discontinued support for Primary Domain Controller (PDC).
Page 136 Chapter 4 System Configuration Joining a Harmonic MediaGrid Cluster to an Apple Open Directory Domain NOTE: If you are using an earlier version of OS X Server on the client computer, access the Open Directory Server Admin Overview Open settings through .
Page 137 Chapter 4 System Configuration Joining a Harmonic MediaGrid Cluster to an Apple Open Directory Domain #superuser_name = omneon #superuser_password = usm admin_group_name = "diradmin" #admin_name = mgadmin #admin_password = 1234 #auth_method = enh-ad auth_method = pam 8. Create a symbolic link between the two LDAP configuration files as follows: mv /etc/openldap/ldap.conf /etc/openldap/ldap.conf.old...
Page 138 Chapter 4 System Configuration Joining a Harmonic MediaGrid Cluster to an Apple Open Directory Domain *host 0 = 2@10.2.3.204/10.2.3.205 id=0xa9b0bff35b416be3 host 1 = 4@10.2.3.200/10.2.3.201 id=0xbf0674ccd8bd5456 host 2 = 4@10.2.3.203/10.2.3.202 id=0x3e4a87f91abd5b43 Opened default session of 0x9279a20 => sess get-users nfsnobody: S-1-22-1-0-1-2--2...
Page 139: Later
IMPORTANT: Before you can perform this procedure, you must install omauthchk.dmg onto the Open Directory server. This file is available with the Harmonic MediaGrid software downloads on the Harmonic website. NOTE: It is not necessary to manually create a ContentBridge account on the Apple Open Directory server.
Page 140 ”mandatory” or “auto.” 3. Verify that /etc/resolv.conf is pointing to the correct nameserver and domain. Configuring gateway.conf 1. Configure /etc/gateway.conf for native access to the Harmonic MediaGrid, as follows: © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 141: Earlier
Bandwidth ContentBridge, it will interfere with authentication when you attempt to access the Harmonic MediaGrid using CIFS. NOTE: In order to access the Harmonic MediaGrid, the individual users must be added to the Apple Open Directory domain. NOTE: If you have previously modified the following configuration files for use with a different directory service, and you are unable to join the High Bandwidth ContentBridge to the Open Directory server (OS X /etc/nsswitch.conf...
Page 142 Chapter 4 System Configuration Joining a Harmonic MediaGrid Cluster to an Apple Open Directory Domain NOTE: It is not necessary to manually create a ContentBridge account on the Apple Open Directory server. Configuring Samba Settings on the High Bandwidth ContentBridge 1.
Page 143: Joining A Contentbridge 1000B To An Open Directory Server With Os X 10.6.8 Or Earlier
Bandwidth ContentBridge, it will interfere with authentication when you attempt to access the Harmonic MediaGrid using CIFS. NOTE: In order to access the Harmonic MediaGrid, the individual users must be added to the Apple Open Directory domain. Joining a ContentBridge 1000B to an Open Directory Server with OS X 10.6.8 or Earlier...
Page 144 Replace opendir_FQDN with the Fully Qualified Domain Name of the Apple Open Directory server. 4. Repeat steps 1-3 for all remaining ContentDirectors in the Harmonic MediaGrid cluster. Adding the Open Directory Server Address to Configuration Files Follow the steps described in Adding the Open Directory Server Address to Configuration Files.
Page 145: Joining A Harmonic Mediagrid Cluster To A Local User Authentication Domain
ContentBridge, it will interfere with authentication when you attempt to access the Harmonic MediaGrid using CIFS. NOTE: In order to access the Harmonic MediaGrid, the individual users must be added to the Apple Open Directory domain. Joining a Harmonic MediaGrid cluster to a Local User...
Page 146: Adding Groups And Users To A Cluster
Chapter 4 System Configuration Joining a Harmonic MediaGrid cluster to a Local User Authentication Domain 4. Save the record and then repeat the steps above for each additional server. Include the server you are currently using. Result: The Managed Servers list displays each server that you added and its connection status between it and the current device.
Page 147: Authentication Configuration Parameters
This PAM configuration for mdscore accounts for the identical (local files then LDAP) ordering. In either order, the ability for the first to provide faulty information overwriting the second is possible. CAUTION: You must have unique users and groups between your authentication server and MediaGrid components to prevent faulty information overwriting.
Page 148: Local User Authentication
Follow these procedures to verify the DHCP settings on both the Primary and Secondary ContentDirectors. To verify DHCP settings: 1. Type the following at the command prompt: sudo /sbin/chkconfig --list dhcpd © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 149: Verifying Contentdirector And Contentserver Communication
Note that the “pid” is a process ID number, which will vary. NOTE: SystemManager provides DHCP status (running or not), as well as failover mode on the ContentDirector Properties page. See the Harmonic SystemManager User Guide for details. Verifying ContentDirector and ContentServer Communication This service ensures that the ContentDirectors are communicating with the ContentServers.
Page 150: Verifying The Mdscore Service Connection
Unable to connect to “localhost”: RPC: Remote system error - Connection refused 2. If the connection is unsuccessful, wait 1 5 minutes and then try connecting again. 3. Type the following command to exit the mdsclientn program: exit © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 151: Verifying Contentserver Disk Space
/mnt/omfs/mds/omneon/omfs/fs0 /mnt Opening Network Ports to Enable Client Access Specific network ports must be open to enable client access to Harmonic MediaGrid. This is particularly important if any security measures, including firewalls, are in place. Harmonic MediaGrid clients must connect to and communicate on TCP ports 10600-10604;...
Page 152: Calculating The Cache Memory Limit
NOTE: The cache memory limit should not exceed 25% of the physical memory. Table 4–2 provides information on how changes to the ReadAhead parameter affect performance. For the currently supported range of readahead values, refer to the Harmonic MediaGrid Release Notes for your client FSD. Table 4–2: Performance Considerations...
Page 153: Setting Memory Usage Parameters On Macintosh Clients
Linux kernel to panic. The gradual increase in memory usage at startup is expected and normal. The Harmonic MediaGrid server cannot be mounted until the pre-allocations are completed. If a mount command is issued immediately after loading the omfs module, the command may fail with an error message indicating, “Some resources could not be allocated, try again later.
Page 154: Configuring The Remote Media Api On A Contentbridge
If necessary, modify the Allocation Limit by entering the following command:  sudo sysctl –w omfs_cache_allocate_limit=NNN where “NNN” is the maximum number of cache memory units (increments of 256KB) To enable the new settings to persist after future reboots, Harmonic recommends that you  /etc/sysctl.conf: edit the same parameters in...
Page 155 ContentBridge to share out a file system from a specific Harmonic MediaGrid cluster via CIFS, FTP, and NFS. The other two types of mount points are utilized only for the Remote Media API. They define remote systems that will be used to transfer media files.
Page 156: Configuring A Contentbridge
191 of 15000 frames copied (31.8 fps) Configuring a ContentBridge Only perform these steps if you add a ContentBridge to an already-configured Harmonic MediaGrid system. The ContentBridge must have a fixed (static) IP address. It is recommended that you assign an IP address from the bottom of the dynamic range and that those addresses be removed from the range.
Page 157: Adding A High Bandwidth Contentbridge To The Harmonic Mediagrid System
CAUTION: If you do not understand the procedures or recommendations described in this chapter, please consult with Technical Support before proceeding. To add a High Bandwidth ContentBridge to the Harmonic MediaGrid system: 1. Connect a monitor and keyboard to the High Bandwidth ContentBridge you wish to add.
Page 158: Contentbridge Configuration Parameters
Use the information from the Harmonic MediaGrid Installation Planning Guide specific to your Harmonic MediaGrid system to complete the answers. Note that the assistant will display suggested responses in brackets. During the assistant, you can use the up or down arrow keys to tab to previous responses.
Page 159: Configuring High Bandwidth Contentbridges In A High Availability (Ha) Pair
FTP, network connectivity, or power fails on the “active” node, the “shadow” node then becomes “active” and takes over operations. Harmonic provides an HA Pair utility that you may run to create an HA pair configuration or remove one.
Page 160 1. Consult your network administrator to identify an available IP address. 2. Make sure no device in your Harmonic MediaGrid system is using the desired IP address. You may log in to the ContentDirector and run one of the following commands to find all the IP addresses in use: nmap -sP <network_address>...
Page 161: Running The Ha Pair Utility
ContentDirector private VLANs for your HA pair subnet. If you choose to use a subnet outside your Harmonic MediaGrid system, make sure to modify your DHCP server to use the shared public address for your HA pair, rather than the public address for a stand-alone High Bandwidth ContentBridge.
Page 162: Possible Uses For The Ha Pair Utility
SystemManager, click the High Bandwidth ContentBridges (in HA icon in the left-hand column and then scroll down to the mode) section of the page. See Figure 4–6. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 163: Configuring A Contentserver
Set the time zone  Using SystemManager, click the View/Edit ContentServer Config button on the Harmonic MediaGrid Cluster Properties page to edit the file. See the Harmonic SystemManager User Guide for complete instructions. The file is located on the ContentDirector at: file.
Page 164: Chapter 5: Installing The File System Driver
IMPORTANT: See the latest Harmonic MediaGrid Release Notes for your particular client platform before installing the file system driver, as there may be changes that are not reflected in this guide. NOTE: It is recommended that you install the file system driver after configuring the Harmonic MediaGrid system.
Page 165: System Requirements
IMPORTANT: You must have administrator privileges to install the Harmonic MediaGrid FSD on Windows platforms. NOTE: If you are upgrading from a prior release of the Windows FSD, Harmonic recommends that you uninstall the previous version. Prior to installing the Harmonic MediaGrid FSD for Windows, make sure of the following: No application is running on the computer.
Page 166: Upgrading From A Prior Windows Fsd Release
Windows from a network location, always copy the installation file to a local directory before beginning the installation. All network drive maps to a Harmonic MediaGrid server are unmapped. To do this, right- click  the mapped network drive and then select the “Disconnect” menu option.
Page 167: Modifying The Osx Ip Stack On The Client
 NOTE: The Mac FSD installation procedure requires administrator access. NOTE: If you are running a pre-3.2 version of the Mac FSD, Harmonic recommends that you first un-install the previous version before installing new software. To uninstall, open a terminal window on the Macintosh and enter the following command:...
Page 168: Settings For Os X 10.9.5 Or Later With Certain Nics
Refer to for instructions. Verifying the Kernel Version Prior to installing the Harmonic MediaGrid FSD for Linux, you need to verify the kernel version. 1. Unpack the downloaded Linux zip file. 2. Enter the password provided by Technical Support. 3. Select the rpm file that matches your distribution. See the list of distributions in the latest Harmonic MediaGrid Linux FSD Release Notes.
Page 169: Installing The Linux Fsd For The First Time
NOTE: Fedora, SLES, Ubuntu, and Debian distributions provide an "omfs.ko" kernel driver module which conflicts with the Harmonic Mediagrid kernel driver module of the same name. In most cases, this is not automatically loaded nor needed. However, you should ensure it is not already in use before replacing it (for example, the command "lsmod | grep omfs"...
Page 170: Harmonic Mediagrid File System Driver For Spectrum
Chapter 5 Installing the File System Driver Harmonic MediaGrid File System Driver for Spectrum All Harmonic MediaGrid file systems are unmounted, using the “umount” Linux command. If  installing the Harmonic MediaGrid Linux FSD from a network location, always copy the installation file to a local directory before beginning the installation.
Page 171: Chapter 6: Accessing The Harmonic Mediagrid
There are two basic methods for accessing the Harmonic MediaGrid system. The first method is to install the file system driver on a client computer and then map to the Harmonic MediaGrid from the client computer. The second method is to use a ContentBridge, which allows you to access the Harmonic MediaGrid via CIFS (Common Internet File System), FTP (File Transfer Protocol) or NFS (Network File System).
Page 172 Figure 6–1: Map Network Drive 3. Enter or select the drive letter to map from the Map Network Drive screen. 4. Enter the Harmonic MediaGrid server name and the file system to mount using a standard UNC pathname, for example: \\10.4.48.201\testfs.
Page 173: Setting Windows Fsd Properties
Mounting a Harmonic MediaGrid File System Using Windows 10. Click You can now access the Harmonic MediaGrid file system on the specified drive. Any mapped drive for this computer through group policy script is available to all users (all sessions).
Page 174: Windows Fsd Property Descriptions
ContentDirector for metadata operations (not file connections Connections transfers). Harmonic recommends that you leave the default value of 8 unless you plan to use an application that requires more than 8 threads to access metadata. © 2017 Harmonic Inc. All rights reserved.
Page 175 Select this option when you wish to prioritize the file close operation and delay the sharing and transfer of modified data to the Harmonic MediaGrid. This may be useful when you are writing to a large number of files, and other clients do not need immediate access to flush mode the files after you have closed them.
Page 176 If your computer has multiple Ethernet ports, Windows FSD allows you to configure which Ethernet port(s) to use for transferring file data to and from the Harmonic MediaGrid. IMPORTANT: After modifying the network settings, you must restart your computer in order for a change to take effect.
Page 177: Automatically Mounting A File System
If you are running an application as a Windows Service, it may be desirable to mount the Harmonic MediaGrid file system without being prompted to enter a user name and password. If Windows is set up to reconnect a share after reboot, the user name and password prompt always displays.
Page 178 7. Include the following line in this file: net use x: \\mdsServerName\mdsFileSystemName /user:<username> <password> Replace <username> with the user name of the Harmonic MediaGrid file system. b. Replace <password> with the password of the Harmonic MediaGrid file system. © 2017 Harmonic Inc. All rights reserved.
Page 179: Using Omcopy For Fast Copying
Mounting the Harmonic MediaGrid from the ProMedia™ Origin Server The ProMedia Origin uses the Windows FSD to allow you to access files on the Harmonic MediaGrid system. Note that the parameters of the Windows FSD on the ProMedia Origin are already optimized for performance and do not require modification.
Page 180: Mounting A Harmonic Mediagrid File System Using A Macintosh
Harmonic MediaGrid file system without using the Harmonic MediaGrid FSD for Macintosh. With version 3.4 and later, the Mac FSD provides two ways to connect to the Harmonic MediaGrid, via a User Mount, which includes security improvements, or via a System Level Mount, which is the same method provided in previous versions.
Page 181 NOTE: If you have specified which network interfaces the client should use for communication with the Harmonic MediaGrid, you may need to update the NIC names after importing settings on a different FSD client, as NIC names may vary across client systems.
Page 182: Connecting To The Harmonic Mediagrid File System
4. Enter the name and password for your Harmonic MediaGrid file system. The domain information can be entered as username/domain. 5. Optionally, you may select the checkbox to add your Harmonic MediaGrid password to your keychain. Adding the password to your keychain allows you to configure your Mac FSD client to connect to Harmonic MediaGrid automatically upon log in, as described in the following section.
Page 183: Connecting With A System Level Mount
Chapter 6 Accessing the Harmonic MediaGrid Mounting a Harmonic MediaGrid File System Using a Macintosh Figure 6–7: Configuring Automatic Connections Connecting with a System Level Mount The System Level Mount uses the same options provided in earlier releases of the Mac FSD.
Page 184 Separate the two names with a forward slash. Finder Name : the Finder name of the connected Harmonic MediaGrid. This name defaults to  the directory entered above, but can be changed to whatever you choose.
Page 185: Unmounting The Harmonic Mediagrid File System
Mounting a Harmonic MediaGrid File System Using a Macintosh Unmounting the Harmonic MediaGrid File System This procedure unmounts the active mount for both user-level and system-level mounts. 1. Open a Finder window, and then click the icon of the Harmonic MediaGrid volume. File Eject Command + E 2.
Page 186: Default
Mounting a Harmonic MediaGrid from a Macintosh in a Windows Domain that is not the Default Macintosh client computers can mount a Harmonic MediaGrid system from a Windows domain, which is not the default using the command prompt. If you haven't created the mountpoint directory yet, you must do so before mounting the file system.
Page 187 Harmonic MediaGrid. readDataPriority=abc This option sets the priority for read operations on the Harmonic MediaGrid file system. Supported types are as shown below in increasing priority level, with the default being omTagPriorityRealTime: omTagPriorityBackground ...
Page 188: Viewing Quota Information From A Macintosh Client
The default value is 8. Viewing Quota Information from a Macintosh Client To view quota information for a given Harmonic MediaGrid directory from a Macintosh client, use the mgquota utitlity provided by Harmonic. For details, see Using the mgquota Utility for the Mac FSD.
Page 189: Additional Mount Options Using Linux
Mounting a Harmonic MediaGrid File System Using Linux To mount a Harmonic MediaGrid file system: 1. Use the type “ ” in the mount command to access the Harmonic MediaGrid file system, omfs for example: mount –t omfs /mediagrid/filesys /mnt –o username=username,password=password NOTE: This information is case-sensitive.
Page 190 Chapter 6 Accessing the Harmonic MediaGrid Mounting a Harmonic MediaGrid File System Using Linux continued Table 6–2: Linux FSD Mount Options Option Description readpri=abc Specify read data priority. The following types are supported: (lowest priority) = background  = low ...
Page 191 Specify the maximum number of handles on a per mount basis. The default value is 64. Setting this to zero will result in the close system call blocking until data is flushed to the Harmonic MediaGrid. Setting this to zero will increase latency times when working with a large number of files. maxsmallfilesize Hint to pre-open prediction code.
Page 192: Using Multiple Client Ethernet Ports
LDAP server. It also uses the domain controller to authenticate the users. The ContentManager and the Harmonic MediaGrid Windows FSD access this user and group information when you use either of them to create ACLs. The ContentManager application and Harmonic MediaGrid Windows FSD also receive the ACLs when either mounts a Harmonic MediaGrid file system, and then they contact the ContentDirector to resolve user names.
Page 193: Linux And Macintosh File Permissions
The other user permission is mapped to the everyone group including the owner. The default Harmonic MediaGrid ACL is all access allowed. A newly created file or directory inherits the ACL from its parent directory.
Page 194: Changing Security Permissions On Windows
Chapter 6 Accessing the Harmonic MediaGrid Managing File and Directory Permissions Figure 6–10: MyDir Properties 3. Click the MediaGrid tab, which shows the following information, depending on what is selected: The version of the Harmonic MediaGrid file system driver installed.
Page 195 Chapter 6 Accessing the Harmonic MediaGrid Managing File and Directory Permissions Figure 6–11: ACL on Harmonic MediaGrid The full path of the selected file or directory is shown at the top of the dialog box, followed by the file/directory owner and user.
Page 196: Viewing File And Directory Permissions On Linux
By default the Harmonic MediaGrid Linux FSD does not reflect the Harmonic MediaGrid ACL security permissions for a file or directory on the Harmonic MediaGrid file system. To have the Linux FSD translate between Harmonic MediaGrid ACLs and Linux mode permission bits on files, use the –o mode option on the mount command line.
Page 197: Using Ftp On A Windows Client
SystemManager User Guide after completing the following for details. The Harmonic MediaGrid file system is exported using a “share name. ” This share name is created using the Harmonic MediaGrid file system name and the account name used to access the file system, as specified in the ContentBridge configuration file.
Page 198: Using Cifs On A Windows Client
ONLY the user specified on the ContentBridge line will be allowed, and will start (root directory) in "path/to/home" if it exists within the MediaGrid. All users other than the ContentBridge user will be rejected. If the specified path does not exist, the user will typically see an FTP error stating: 500 OOPS: cannot change directory:/mnt/omfs/<path_to_mediagrid>...
Page 199: Using Cifs On A Linux Client
Chapter 6 Accessing the Harmonic MediaGrid Connecting Clients to Harmonic MediaGrid Using ContentBridge Using CIFS on a Linux Client Follow these steps to access the Harmonic MediaGrid from a Linux client. To use CIFS: 1. Type the following at the command prompt: mount -t cifs -o username=<USERNAME>\\\\<CLB>\\<SHARE NAME>...
Page 200: Chapter 7: Administrative Procedures
ContentServer or ContentStore involved. Please read the following sections carefully and plan accordingly. NOTE: Capacity expansion requires Harmonic MediaGrid version 3.5 or later (on all components in your Harmonic MediaGrid system) and SystemManager 6.2.3 or later. About Shelf Evacuation ...
Page 201: About Write Bandwidth During Shelf Evacuation
About Write Bandwidth During Shelf Evacuation Although the Harmonic MediaGrid system can still service read and write requests during shelf evacuation, note that write bandwidth will be reduced both by the portion represented by the shelf being evacuated and by the overhead of copying slices to the other shelves.
Page 202: About Setting Shelves To Read-Only Mode
ONLY. Do not set a shelf as read-only for any other purpose. By default, Harmonic MediaGrid distributes content that has been evacuated from one shelf equally across all remaining shelves in the volume or group. This has the advantage of maintaining maximum possible read bandwidth.
Page 203: Expanding Drive Capacity In A Harmonic Mediagrid Raid System
Priority 2. From the drop-down menu, select the priority level for evacuation: Normal : Select if the Harmonic MediaGrid cluster will be in use (reads or writes are taking  place) during shelf evacuation. High : Select if the Harmonic MediaGrid cluster will be idle (no reads or writes are taking ...
Page 204 Lastly, after a short delay, SystemManager shows an estimated time of completion. This estimate is based on the rate at which the Harmonic MediaGrid has copied slices so far, and the number of slices remaining, without regard to slice sizes. This estimate will change with increased/decreased load on the system or network, or with significant variation in the size of slices to be moved.
Page 205: Possible Errors During Shelf Evacuation
Unable to migrate slice: <SID>. Evacuation canceled.  Unable to migrate slice: <SID>. Evacuation of SSID=<SSID> canceled. Once the Harmonic MediaGrid is stable, confirm that there is still sufficient space to evacuate the Step 4 shelf. Return to in the previous procedure.
Page 206: Setting The Contentstore 5840 Identification Number
“99” are valid. Enabling Directories with More than 15 Levels With version 3.4 and later, you may enable your Harmonic MediaGrid file system to contain directories with more than 1 5 levels. CAUTION: Before enabling this support, please note that moving to an earlier release after having created directories deeper than 15 levels is not supported.
Page 207: Disabling Directories With More Than 15 Levels
NOTE: Any ContentDirectors, which start up while the current cluster members are down will not receive the changes so Harmonic recommends first having all ContentDirectors running at this point. Client applications will now be able to create directories whose depth is only limited by the overall path limit (1024 bytes, which will be fewer than 1024 characters for non-ASCII character sets).
Page 208: Using Mgcopy To Copy Files Between Harmonic Mediagrid Systems
-bash: cd: d/d: No such file or directory Using mgcopy to Copy Files Between Harmonic MediaGrid Systems The mgcopy utility allows you to copy data quickly between Harmonic MediaGrid systems. This utility can be used any time you wish to back up data quickly.
Page 209 Chapter 7 Administrative Procedures Using mgcopy to Copy Files Between Harmonic MediaGrid Systems When opened, mgcopy presents a command line interface. Use the mgcopy command with additional values shown in Table 7–1 to perform a copy. Note the following usage:...
Page 210 Used with other options like copyAcl and copyOwner, but does not copy data at destination -testRun Do a test run of the command to see if the version of source and destination Harmonic MediaGrids are compatible with each other Debug level (default: 0)
Page 211: Using The Mgquota Utility For The Mac Fsd
The mgquota utility is installed and run on a Mac FSD client and displays quota information for a given Harmonic MediaGrid directory. It does not allow you to set a quota; it merely reports the quota for the specified directory. For information on setting a quota, refer to the Harmonic ContentManager User’s Guide.
Page 212 Chapter 7 Administrative Procedures Upgrading Harmonic MediaGrid Firmware 2. In the Harmonic MediaGrid column, click the radio button for the desired firmware version. The red check mark indicates the selected version. 3. When the confirmation dialog appears, click to accept.
Page 213: Powering Down A Harmonic Mediagrid System
5.10 or later and Harmonic MediaGrid version 2.1SR3 or later. If your version of SystemManager is earlier than 5.10 or if your version of Harmonic MediaGrid is earlier than 2.1SR3, refer to the version of the Harmonic MediaGrid Installation and Configuration Guide that accompanies your software.
Page 214 Chapter 7 Administrative Procedures Powering Down a Harmonic MediaGrid System Figure 7–3: Shut down all ContentDirectors in a cluster 4. A confirmation message appears. Click ContentDirectors 5. Scroll down to the section of the page. Make sure the Network Status of the...
Page 215: Powering Down Or Restarting A Single Contentdirector
Chapter 7 Administrative Procedures Powering Down a Harmonic MediaGrid System Start Shut 1 3. From the SystemManager platform, click the button on the taskbar, and then click Down to shut down the SystemManager platform. Disconnect the power cord if necessary.
Page 216: Powering Down A Single Contentserver
LEDs are off, disconnect the power cables from the power supplies. Powering On a Harmonic MediaGrid System Use the following steps to power on the devices in a Harmonic MediaGrid system. IMPORTANT: The procedures must be followed in the order described below.
Page 217: Logging On To A Contentdirector
This section provides information about managing the network switches. Changing the Default Network Switch User Name and Password Each network switch is preset with the following user name and password: User name: Administrator  Password: omneon  © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 218: Upgrading The Network Switches
Press ‘Enter’ and start XMODEM on your host... 4. Press Enter to continue. 5. Select Send File from the Transfer menu on the HyperTerminal menu bar. The Send File window appears. Figure 7–4: Send File © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 219 Press ‘Enter’ and start XMODEM on your host... 5. Press Enter to continue. 6. Select Send File from the Transfer menu on the HyperTerminal menu bar. A Send File window appears. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 220: Installing Harmonic Mediagrid And Contentdirector Software
The Dell license agreement displays on the ContentDirector followed by a prompt to install an operating system if the Harmonic MediaGrid operating system software is not installed. The Harmonic MediaGrid operating system software is installed if the ContentDirector boots up in Linux.
Page 221: Installing The Harmonic Mediagrid Operating System Software
ContentDirector software. To install the ContentDirector platform support package: 1. Insert the “Harmonic MediaGrid Platform Support Package” CD-ROM into the DVD drive. 2. Using an attached keyboard and monitor, log on to the ContentDirector as “ovnuser” using the password “OVN@SvCaUsa”.
Page 222: Installing The Contentdirector Software
User Guide to upgrade ContentDirectors with the latest version of software. To install the ContentDirector software for the first time: 1. Insert the “Harmonic MediaGrid Software Installation” CD-ROM into the DVD drive. 2. Using the attached keyboard and monitor, log on to the ContentDirector as “ovnuser” using the password “OVN@SvCaUsa”.
Page 223: Chapter 8: Hardware Reference
Chapter 8 Hardware Reference This chapter provides descriptions of the components used in a Harmonic MediaGrid system. For information on legacy hardware platforms, refer to Appendix A, Legacy Hardware Platforms. The following topics are included: ContentDirector 1000F and High Performance ContentDirector 2000C ...
Page 224 Private: NIC 2 connection failure SSD 0 Drive failure Magenta Public: NIC 1 connection failure Private: NIC 3 connection failure SSD 1 Both connections have failed Figure 8–2: ContentDirector Front Panel Indicators © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 225 The LCD lights blue during normal system operation. The LCD lights amber when the system needs attention, and the LCD panel displays an error code followed by descriptive text. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 226 8. Hard drive 1 High Performance ContentDirector 2000C 7. Solid-state drive 0 Refer to Table 8–6 for a description of the indicator codes 8. Solid-state drive 1 © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 227 When the power-on indicator is off, this indicates that no power is supplied to the system. 8. Drive activity LED Indicates drive activity. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 228 IMPORTANT: Do not turn off power when replacing a drive. As soon as the new drive is inserted, the system will begin replicating the data from the other drives. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 229: Rear Panel Components
System ID LED on the front Control Panel. When that button is pushed, this LED flashes blue until the button is pressed again. 1 3. Baseboard Management Do not use. Console (BMC) connector © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 230 NOTE: The indicator codes for NIC 0 and NIC 1 differ from the indicators codes for NIC 2 and NIC 3. Figure 8–8: ContentDirector NIC 0 and NIC 1 LED Indicator Codes © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 231: Contentbridge 2010F
The ContentBridge 2010F (also referred to as the High Bandwidth ContentBridge), an optional component, provides access to Harmonic MediaGrid for those client platforms that do not have the FSD installed or do not use the Harmonic MediaGrid API. The ContentBridge 2010F provides the highest throughput of the ContentBridge models.
Page 232 A peer failure has a occurred. Off/Blue HA Pair has not been configured. Hard Drive 0 White Drive is online. Hard Drive 1 Yellow Drive replacement warning. A drive failure has occurred. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 233 8. Solid state drive 1 Control Panel Indicators Figure 8–13 Table 8–12 describe the Control Panel buttons and LED states. Figure 8–13: Control Panel Indicators © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 234 When the power-on indicator is off, this indicates that no power is supplied to the system. 8. Drive activity LED Indicates drive activity. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 235 IMPORTANT: Do not turn off power when replacing a drive. As soon as the new drive is inserted, the system will begin replicating the data from the other drives. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 236: Rear Panel Components
Located on the back edge of the server board, this LED matches the state of the System Status LED on the front Control Panel. Refer to Table 8–13 for a description of each LED state. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 237 Figure 8–17: ContentBridge 2010F 1 Gigabit Ethernet LED Indicator Codes Link/Activity Speed Green = 1 Gbps Green (blink) = activity Yellow = 100 Mbps Green (solid) = link Off = No link Off = no link © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 238: Contentserver 3000
The ContentServer 3000 presents data to clients, managing the actual data on the hard drives. Front Panel Components Front Bezel Figure 8–19 Table 8–18 describe the front bezel components of the ContentServer 3000. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 239 ContentServer 3000 with the front bezel removed and all disk drives in place. Drive 15 Drive 0 Figure 8–20: ContentServer 3000 Front Panel © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 240 2. Disk drives The server contains 16 SATA or SAS disk drives, providing storage for the Harmonic MediaGrid. Drives are numbered from right to left when facing the front panel. 3. Power button and Right Control...
Page 241 Indicates a power supply module has failed. Refer to the Harmonic MediaGrid Component Replacement Guide for details on replacing the power supply. Heartbeat Flashing Indicates that power is being supplied to the server board © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 242 Figure 8–22 Table 8–21 for information on the Disk Drive Status LEDs. Refer to the Harmonic MediaGrid Component Replacement Guide for instructions on replacing a failed drive. LEDs Figure 8–22: Disk Drive Status LEDs Table 8–21: Disk Drive Status LEDs...
Page 243: Rear Panel Components
The ContentServer 3000 includes two separate controllers, and two power supplies to provide redundancy in the case of a failure. Figure 8–23 Table 8–22 describe the rear panel components of a ContentServer 3000. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 244 IMPORTANT: Note that, when facing the rear of the chassis, the controller on the left side of the chassis corresponds to Controller 0 in SystemManager, and the controller on the right side of the chassis corresponds to Controller 1 in SystemManager. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 245 9. Optional Ethernet cards: An optional 10 Gigabit Ethernet card with two ports is Optional 2x10GbE Add in Card available from Harmonic. For details on the LED states,  Optional 4x1 GbE Add-in Card refer to 10-Gigabit Ethernet Add-in Card LED ...
Page 246 NVRAM Card Figure 8–25: NVRAM Card LEDs Table 8–24: NVRAM Card Status LEDs LED State Description 1. Restore Data from the NVRAM is being restored to DRAM. No activity. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 247 Power off, network cables unplugged Green (solid) Power off, network cables plugged in. Active connection at 100 Mb/s Yellow (solid) Power on, network cables plugged in. Active connection at 1 Gb/s © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 248 Table 8–26: 10 Gigabit Ethernet Add-in Card status LED LED State NIC State Power off, network cable unplugged Green (solid) Active connection at 10 Gb/s. Green (blink) Network data being sent or received. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 249: Contentserver 4000
3. Control panel Shows Operational State and Fault indicators for both Controller A and Controller B. For information about LED indicators, refer to Table 8–29. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 250 A critical error has occurred. No critical errors have occurred. Disk Drive Numbering Drives are number 0-23, starting with the top left drive. Figure 8–30: ContentServer 4000 Drive Numbering © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 251: Rear Panel Components
The ContentServer 4000 rear panel includes mini-SAS HD ports for connecting to multiple ContentStore nodes. Controller A corresponds with the upper module and Controller B corresponds with the bottom module. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 252 Figure 8–32: ContentServer 4000 Rear Panel View Table 8–31: ContentServer 4000 Rear Panel Components Item Description 1. Power supply 0 The ContentServer 4000 includes dual redundant power supplies. 2. Power supply 1 © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 253 Used for maintenance purposes only. 7. Mini SAS HD connectors (4) Used for connecting the ContentServer to ContentStores. CAUTION: With Harmonic MediaGrid 4.0, SAS cables are not hot-swappable. When replacing or removing a SAS cable, you must first power down the associated ContentServer controller...
Page 254: Contentstore 3160
The ContentStore 3160 presents data to the client, managing the actual data on the hard drives. Front Panel Components Bezel Figure 8–35 Table 8–34 describe the front bezel components of the ContentStore 3160. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 255 Front Panel View Figure 8–36 Table 8–35 detail the front view of the ContentStore 3160 with the front bezel removed and all disk drives in place. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 256 2. Disk drives The server contains 16 SATA or SAS disk drives, providing storage for the Harmonic MediaGrid.Drives are numbered from right to left when facing the front panel. 3. Power button and Right Control...
Page 257 Indicates that the SAS output port is connected. Power Fail Solid Indicates a power supply module has failed. Refer to the Harmonic MediaGrid Component Replacement Guide for details on replacing the power supply. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 258 Figure 8–38 Table 8–37 for information on the Disk Drive Status LEDs. Refer to the Harmonic MediaGrid Component Replacement Guide for instructions on replacing a failed drive. LEDs Figure 8–38: Disk Drive Status LEDs © 2017 Harmonic Inc. All rights reserved.
Page 259: Rear Panel Components
Table 8–38: ContentStore 3160 Rear Panel Components Component Description 1. Power supplies Dual, redundant power supplies provide power to the system. For a description of the power supply LED states, refer to Power Supply LED © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 260: Contentstore 4240
ContentServer and other ContentStores. Left port: Input Right port: Output CAUTION: With Harmonic MediaGrid 4.0, SAS cables are not hot-swappable. When replacing or removing a SAS cable, you must first power down the associated ContentServer controller using SystemManager, replace...
Page 261 2. Control Panel Displays power, temperature, fan, and system status LED indicators. 3. System mute button Unused (alarm disabled). 4. Bezel LED control Powers the light bar on the bezel. connector © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 262 System fault detected. Temperature Temperature is normal. System is overheating. Fans are operating normally. Fan fault detected. Disk Drive Numbering Drives are number 0-23, starting with the top left drive. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 263 Drive is powered on Solid Drive activity Blink RAID rebuild in progress Blink Slow blink (1 Hz) Drive failure Solid Rapid blink (2Hz) Drive is being winked Slow blink (1Hz) © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 264: Rear Panel Components
2. Expander modules Provides SAS I/O ports. May be replaced in the event of a failure. CAUTION: With Harmonic MediaGrid 4.0, SAS cables are not hot-swappable. When replacing or removing a SAS cable, you must first power down the associated ContentServer controller using...
Page 265 D/C LED Warning LED PSU normal, A/C present Solid Solid No A/C to PSU Slow blink (1Hz) Solid PSU warning Solid Slow blink (1Hz) PSU failure Solid No A/C input © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 266: Contentstore 5840 And 5840A
Each drawer can be locked shut by turning both anti- tamper locks clockwise using a screwdriver with a Torx T20 bit 6. Drawer 1 The top drawer. Each drawer contains 42 drive slots. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 267: Drive Numbering
Figure 8–47: ContentStore 5840 and 5840A Drive numbering Operator’s Panel The operator’s panel on the front of the ContentStore 5840 and 5840A displays the aggregated status of all the modules. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 268 Drawer 1/Drawer2 Fault Amber indicates a fault in a drive, cable, or sideplane for the specified drawer. Drawer LEDs The ContentStore 5840 and 5840A drawer LEDs display status for individual drawers. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 269 Amber if a drawer component has failed. If a drive has failed, an amber LED will be lit on the failed drive, and the drive should be replaced (for details, see the Harmonic MediaGrid Component Replacement Guide). If the drives are OK, contact Harmonic Technical Support to identify the failure.
Page 270 Figure 8–50. When lit, this indicates a drive failure – the drive should be replaced as soon as possible. For details, see the Harmonic MediaGrid Component Replacement Guide. NOTE: Interchanging disks between the ContentStore 5840 and 5840A is not supported.
Page 271: Contentstore 5840 Rear Panel Components
I/O module bay must be filled with a blank module. CAUTION: With Harmonic MediaGrid 4.0, SAS cables are not hot-swappable. When replacing or removing a SAS cable, you must first power down the associated ContentServer controller...
Page 272 For details, see the Harmonic MediaGrid Component Replacement Guide. 10. PSU Release Latch Use when removing a PSU, as described in the Harmonic MediaGrid Component Replacement Guide. 1 1. PSU LEDs For a description of LED states, see ContentStore 5840A Cooling Module LEDs.
Page 273 AC power present, PSU in standby (other PSU is providing power.) Flashing Flashing PSU firmware download. AC power missing, PSU in standby (other PSU is providing power). Harmonic MediaGrid software has lost communication with the PSU. Disregard PSU has failed. For replacement instructions, see the Harmonic MediaGrid Component Replacement Instructions.
Page 274: Contentstore 5840A Rear Panel Components
I/O module bay must be filled with a blank module. CAUTION: With Harmonic MediaGrid 4.0, SAS cables are not hot-swappable. When replacing or removing a SAS cable, you must first power down the associated ContentServer controller...
Page 275 For details, see the Harmonic MediaGrid Component Replacement Guide. 10. PSU Release Latch Use when removing a PSU, as described in the Harmonic MediaGrid Component Replacement Guide. 1 1. PSU LEDs For a description of LED states, see ContentStore 5840A Cooling Module LEDs.
Page 276 Description 1. Fault and OK Fault: Constant amber if the I/O module is faulty. For replacement instructions, see the Harmonic MediaGrid Component Replacement Guide. OK: Constant green if the I/O module is operating correctly. Flashing green indicates an I/O module VPD error.
Page 277: 5406 Network Switch
8–60, and Figure 8–61 show the front and rear views. NOTE: The 5406 Network Switch may be used in a Harmonic MediaGrid 3000 Series system, but not in a 4000 Series system. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 278 Self Test LED Figure 8–59: Front View of 5406 Network Switch (10GbE and 1GbE Ports) Figure 8–60: Front View of 5406 Network Switch (All-1GbE Ports) © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 279: Power And Cooling Specifications
IMPORTANT: The ContentServer 3000/4000 series cannot be connected directly to CX4 ports. Power and Cooling Specifications Note the following power and cooling specifications for Harmonic MediaGrid devices. Table 8–56: Power and Cooling Specifications Device Input Power...
Page 280 1 436 BTU/hr @ 421 W ContentStore 5840 with 6 TB drives 200-240, 60-50Hz 6261 BTU/hr @ 1835 W ContentStore 5840 with 4 TB drives 200-240, 60-50Hz 6510 BTU/hr @ 1908 W © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 281: Chapter 9: Troubleshooting
The archive depth is presently 1 3 files deep but can be configured to archive more files. Harmonic MediaGrid breaks the log files out by IP address for each of the devices in the cluster. ContentServers have two log files so long as the IP interfaces are up and active.
Page 282: Verifying The Dhcp Server Is Running On The Contentdirectors
Verifying the DHCP Server Is Running on the ContentDirectors The first two ContentDirectors in a Harmonic MediaGrid have DHCP servers running on them and they are configured as peers. This means that either of the ContentDirectors can respond to a DHCP request and the servers should communicate the IP address that they have assigned to a request to the other DHCP server.
Page 283: Checking Log Files For Errors
[root@CDL1 dhcp]# pgrep dhcpd 3027 As mentioned before, the DHCP servers in the Harmonic MediaGrid are configured in a peer relationship. Both servers have to be up or one must timeout and wait for the other to come online. In the output of /var/log/messages below, the communication between ContentDirector1 (shown as CLD1) and ContentDirector2 (shown as CLD2) has been interrupted.
Page 284: Network Time Protocol (Ntp)
Network Time Protocol, or NTP, is a way of updating the time on a computer to a known time reference. For the Harmonic MediaGrid this is essential because while all the computers in the cluster function as a system, they are still autonomous. To synchronize time between ContentDirectors, the ntp.conf file on all ContentDirectors in the Harmonic MediaGrid are...
Page 285: Troubleshooting On The Contentbridge
“ntpdate -u” can then be initiated on ContentDirectors that are receiving the above error message. Troubleshooting on the ContentBridge The ContentBridge provides access to the Harmonic MediaGrid for clients not running the FSD or clients that need to access the Harmonic MediaGrid via FTP. ContentBridge Mounts to the Harmonic MediaGrid The primary problem experienced with the ContentBridge occurs when the Harmonic MediaGrid file system has not been mounted.
Page 286: Contentbridge Configuration Files
In addition to the config file on the first two ContentDirectors, there is a gateway file for each ContentBridge in the Harmonic MediaGrid. The file name for the gateway file is CLBnnnnn and is case sensitive. The five n’s reflect the last five digits of the serial number of the ContentBridge.
Page 287: Contentbridge Services
NOTE: If you are using a name instead of an IP address for the ContentBridge, make sure you can ping the name. If not, DNS is not configured correctly. NOTE: Note that lines starting with “MG” or “CI” are for access via the Harmonic Media API, and lines starting with “CB” are for access via CIFS/SMB or FTP.
Page 288 [password | *]] [/USER:[domainname\]username] [/USER:[dotted domain name\]username] [/USER:[username@dotted domain name] [/SMARTCARD] [/SAVECRED] [[/DELETE] | [/PERSISTENT:{YES | NO}]] NET USE {devicename | *} [password | *] /HOME NET USE [/PERSISTENT:{YES | NO}] © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 289: Authenticating Domain User With Mdsclientn Or Wbinfo Commands
The output of a “net join” is captured into a file named 'log-wb[domain name]'. This log file can be utilized to view failures of a join or to view success messages for the join. The following is an example of one such log file: less /var/log/samba/log.wb-SNV-TAC © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 290: Using Sessions To Determine A Client Ip Address
IP would not work. Active Connections to the Harmonic MediaGrid: MDS Sessions To determine what clients are connected to the Harmonic MediaGrid, the following command can be issued on any of the ContentDirectors. It will display each connection which includes IP information as well as duration and the User Session ID.
Page 291: Understanding Device, Usm, And Snmp Errors In Systemmanager
9–1, the sliced process was not running, which resulted in In the example shown in Down Troubleshooting the ContentStore 5840 The following sections describe problems that can occur with your ContentStore 5840 and some possible solutions. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 292: Thermal Monitoring And Control
The ContentStore 5840 uses extensive thermal monitoring and takes a number of actions to ensure component temperatures are kept low and also to minimize acoustic noise. Air flow is from the front to the rear of the enclosure. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 293: Thermal Alarm
Use of the enclosure in a fully enclosed rack is not recommended. If possible shutdown the enclosure  and investigate the problem before continuing. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 294: Troubleshooting A Component, Cluster, Or Client Failure
Troubleshooting a Component, Cluster, or Client Failure In order to expedite diagnosis and remediation, please gather helpful information about your Harmonic MediaGrid system as well as your SystemManager platform when contacting Technical Support. Gathering Information about the SystemManager Client PC ...
Page 295: Gathering Information About A Harmonic Mediagrid Cluster Failure
If any reading is beyond the expected range, this may indicate a failed or failing component. Refer to the Harmonic SystemManager User Guide for more information about the properties shown in this section.
Page 296: Determining The Fsd Version
By default, the logging level is set to Setting Windows FSD For instructions on accessing the Windows File System Driver, refer to Properties. 5 - Debug 1. Using the Windows FSD, increase the logging level to © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 297 Chapter 9 Troubleshooting Troubleshooting a Component, Cluster, or Client Failure NOTE: For debug to take effect, the Harmonic MediaGrid system must be mounted. 2. Apply changes to any other parameters at the request of Technical Support. Apply 3. Click and then The changes take effect immediately.
Page 298: Appendix A: Legacy Hardware Platforms
ContentDirector 1000B/1000C/1000D and High Performance ContentDirector 2000 ContentDirectors manage and direct the overall operation of Harmonic MediaGrid. They enable clients to interact with the system by creating and presenting a single virtual file system constructed from Harmonic MediaGrid’s many individual ContentServer storage devices.
Page 299 ContentDirector with the bezel removed. Note that your ContentDirector may differ somewhat from the one described below. < > Figure A–3: Front View of ContentDirector © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 300 Available only in the High Performance ContentDirector 2000. Figure A–4 Table A–4 describe the typical hard drive indicators and their functions. Drive-status Indicator (green and amber) Drive-activity Indicator (green) Figure A–4: ContentDirector Hard Drive Indicators © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 301 Use for Gigabit Ethernet connection to switch. 5. NIC 1 connector Use for Gigabit Ethernet connection to switch. 6. NIC 2 connector Use for Gigabit Ethernet connection to switch. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 302 To correct this, replace the power supply that has the flashing indicator with a power supply that matches the capacity of the other installed power supply. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 303: Contentdirector 1000E And High Performance Contentdirector 2000B
ContentDirector 1000E and High Performance ContentDirector 2000B ContentDirectors manage and direct the overall operation of Harmonic MediaGrid. They enable clients to interact with the system by creating and presenting a single virtual file system constructed from Harmonic MediaGrid’s many individual ContentServer storage devices.
Page 304 Ethernet communications OK Hard Drive 0 NIC 1 Link Ethernet communications problem White Drive status OK NIC 2 Link Hard Drive 1 Drive error Figure 9–3: ContentDirector Front Panel Indicators © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 305 Press to toggle the system ID on and off. 3. Video connector Connects a monitor to the system. 4. LCD menu buttons Allows you to navigate the control panel LCD menu. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 306 Blinks amber four times per Drive failed second Blinks green slowly Drive rebuilding Steady green Drive online Blinks green three seconds, Rebuild aborted amber three seconds, and off six seconds © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 307: Rear Panel Components
Dual redundant power supplies provide power to the system. 10. Power supply 2 Power Supply Indicator/Handle Figure 9–7 Table 9–8 describe the typical Redundant Power Supply Indicator/Handle and its functions. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 308 Each NIC on the rear panel has an indicator that provides information on network activity and link Figure A–7, and Table 9–9 status. detail the NIC indicators and the possible states of each. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 309: Contentbridge 1000
ContentBridge 1000 The ContentBridge 1000, which is an optional Harmonic MediaGrid system component, provides access to the Harmonic MediaGrid for those client platforms that do not have the File System Driver (FSD) installed or do not use the Harmonic MediaGrid API.
Page 310: Rear Panel Components
Note: Blinking is a quick on and off state; winking spans a longer period (1.5 seconds). Rear Panel Components Figure A–8 Table A–10 describe the rear panel view of a typical ContentBridge 1000. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 311 Table A–11: ContentBridge 1000 Ethernet Port Status LED Color LED State NIC State Green/amber (left) 10 Mbps Green 100 Mbps Amber 1000 Mbps Green (right) Active connection Blinking Transmit/receive activity © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 312: Contentbridge 1000B
ContentBridge 1000B ContentBridge 1000B The ContentBridge 1000B, an optional Harmonic MediaGrid system component, provides access to Harmonic MediaGrid for those client platforms that do not have the FSD installed or do not use the Harmonic MediaGrid API. Front Panel Components Figure A–9...
Page 313: Rear Panel Components
Indicates Ethernet link problem Power off Rear Panel Components Figure A–11 Table A–14 detail the rear panel view of the ContentBridge 1000B. Figure A–11: Rear View of ContentBridge 1000B © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 314 Power off, network cables unplugged Green (solid) Power off, network cables plugged in. Active connection at 100 Mb/s Amber (solid) Power on, network cables plugged in. Active connection at 1 Gb/s © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 315: Contentbridge 2010B/C/D (High Bandwidth)
Harmonic MediaGrid for those client platforms that do not have the FSD installed or do not use the Harmonic MediaGrid API. The High Bandwidth ContentBridge provides the highest throughput of the ContentBridge models. Note the ContentBridge 2010D includes 1TB drives and the 2010C includes 250 GB drives.
Page 316 Figure A–15 Table A–18 detail the front panel view of a typical ContentBridge 2010B/C/D with the bezel removed. Note that your ContentBridge may differ somewhat from the one described below. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 317 8. Hard drive 0 Refer to Table A–19 for a description of the indicator codes. 9. Hard drive 1 Figure A–16 Table A–19 describe the typical hard drive indicators and their functions. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 318: Rear Panel Components
Figure A–17: Rear View of ContentBridge 2010B/C/D Table A–20: ContentBridge 2010B/C/D Rear panel components Indicator, Button, or Connector Description 1. Serial connector Use to connect a serial device to the system © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 319 1 1. Power supply 2 10 Gigabit Ethernet LEDs Figure A–18 Table A–21 describe the possible states of the 10 Gigabit Ethernet LEDs. Receive Activity Link Transmit Figure A–18: 10 Gigabit Ethernet LEDs © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 320 IMPORTANT: Do not turn off power when replacing a drive. As soon as the new drive is inserted, the system will begin replicating the data from the other drives. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 321: Contentbridge 2010E
ContentBridge 2010E The ContentBridge 2010E (also referred to as the High Bandwidth ContentBridge), an optional component, provides access to Harmonic MediaGrid for those client platforms that do not have the FSD installed or do not use the Harmonic MediaGrid API.
Page 322 Figure 9–11 Table 9–12 detail the front panel view of a typical ContentBridge 2010E with the bezel removed. Note that your ContentBridge may differ somewhat from the one described below. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 323 8. Hard drive 0 Refer to for a description of the indicator codes. 9. Hard drive 1 Figure 9–12 Table 9–13 describe the typical hard drive indicators and their functions. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 324: Rear Panel Components
IMPORTANT: Do not turn off power when replacing a drive. As soon as the new drive is inserted, the system will begin replicating the data from the other drives. Rear Panel Components Figure 9–13 Table A–20 describe the rear panel view of the ContentBridge 2010E. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 325 Dual redundant power supplies provide power to the system. 9. Power supply 2 10 Gigabit Ethernet LEDs Figure 9–14 Table 9–15 describe the possible states of the 10 Gigabit Ethernet LEDs. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 326 AC power is not connected. Green The handle indicator lights green indicating that a valid power source is connected to the power supply and that the power supply is operational. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 327 (in terms of efficiency, feature set, health status, and supported voltage). Replace the power supply that has the flashing indicator with a power supply that matches the capacity of the other installed power supply. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 328: Appendix B Contentdirector Limits
Harmonic MediaGrid release 3.1 and later. This section provides an explanation of the implementation of ContentDirector limits in Harmonic MediaGrid 3.1 and later as well as information needed to plan the capacity and monitor resource consumption of Harmonic MediaGrid system.
Page 329 * Standard ContentDirectors with file counts greater than 1 million are supported when upgraded to Harmonic MediaGrid 3.1 or later provided that the other limits are met. However, load and restart times will increase as file counts increase beyond the recommended limit. To improve load and restart times with file counts beyond the recommended limit, upgrade to the High- Performance ContentDirector.
Page 330: Resource Limits
FileTable space. SliceTable Slices Harmonic MediaGrid 3.1 or later manages the size of its SliceTable in terms of the count of distinct slices. In systems using replication, the SliceTable only counts 1 for all copies of a slice.
Page 331: Capacity Planning
 restart time. Estimate the number as part of planning for whether you need to consider upgrading to a High-Performance ContentDirector. In Harmonic MediaGrid 3.1 or later, the largest uses of dynamic memory are:  Dynamic per-node structure (namebind) ...
Page 332: Monitoring Resource Consumption
For each pool, “Total Allocated” is represented in bytes and “Available” is represented in units  of data structure instances. Figure B–1 shows an example of an mdscore log file. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release 4.1...
Page 334: Appendix A: Contacting The Technical Assistance Center
Appendix A Contacting the Technical Assistance Center Harmonic Global Service and Support has many Technical Assistance Centers (TAC) located globally, but virtually co-located where our customers can obtain technical assistance or request on-site visits from the Regional Field Service Management team. The TAC operates a Follow-The- Sun support model to provide Global Technical Support anytime, anywhere, through a single case management and virtual telephone system.
Page 335 Harmonic Inc. 4300 North First St. San Jose, CA 951 34, U.S.A. Attn: Customer Support The corporate telephone numbers for Harmonic Inc. are: Tel. 1.800.788.1 330 (inside the U.S.) Tel. +1.408.542.2500 (outside the U.S.) Fax.+1.408.542.251 1 © 2017 Harmonic Inc. All rights reserved.
Page 336: Appendix B: Safety And Regulatory Compliance Information
Legal Disclaimer: Information in this document is provided in connection with Harmonic products. Unless otherwise agreed in writing Harmonic products are not designed nor intended for any application in which the failure of the product could cause personal injury or death.
Page 337 Leave the back of the frame clear for air exhaust cooling and to allow room for cabling - a minimum of 6 inches (1 5.24 cm) of clearance is recommended. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release Release 4.1, Rev A...
Page 338 Avoid contact between the cards and clothing.  Periodically check the resistance value of the antistatic strap.  Recommended value is between 1 and 10 mega-ohms (Mohms). © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release Release 4.1, Rev A...
Page 339 Dispose of used batteries according to the manufacturer's instructions  There are no user-serviceable batteries inside Harmonic products. Refer  to Harmonic qualified personnel only to service the replaceable batteries Caution Symboles de sécurité et traduits de sécurité, d'avertissement et Attention Instructions (français) Pour éviter des blessures ou des dommages matériels, avant de commencer l'installation ou le...
Page 340 Dégager l'arrière du cadre pour permettre le refroidissement de l'évacuation d'air et laisser de la place au câblage; un dégagement d'au moins 1 5.24 cm (6 po) est recommandé. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release Release 4.1, Rev A...
Page 341 Lors du retrait de l'unité, retirer le raccordement de terre seulement après avoir mis l'unité à l'arrêt et l'avoir débranchée. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release Release 4.1, Rev A...
Page 342 Mettre au rebut les batteries usagees conformement aux instructions du  fabricant. Les batteries des produits Harmonic ne peuvent pas être réparées ni  entretenues par l'utilisateur. Ne confier l'entretien des batteries remplaçables qu'à du personnel compétent de Harmonic.
Page 343 Lassen Sie die Rückseite des Rahmens frei für Abluftkühlung und um Platz für die Verkabelung ermöglichen - ein Minimum von 6 Zoll (1 5,24 cm) Abstand wird empfohlen © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release Release 4.1, Rev A...
Page 344 Zahnstange wurde korrekt vor dem Einschalten des Gerätes geerdet. Beim Entfernen der Einheit entfernen Sie die Masseverbindung nur, nachdem das Gerät ausgeschaltet und der Netzstecker gezogen. © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release Release 4.1, Rev A...
Page 345 Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr  Entsorgen Sie die benutzten Batterien nach den Anweisungen des  Herstellers. Es gibt keine zu wartenden Akkus im Harmonic Produkte. Siehe Harmonic  qualifiziertes Personal, um die austauschbare Batterien Service Vorsich Site Preparation Instructions NOTE: Only trained and qualified service personnel (as defined in IEC 60950 and AS/NZS 3260) should install, replace, or service the equipment.
Page 346 Do not move or ship equipment unless it is correctly packed in its original wrapping and  shipping containers. Only allow Harmonic trained personnel to undertake equipment service and  maintenance. Do not permit unqualified personnel to operate the unit.
Page 347 Recycler personnel shall be experienced with using the proper tools required for disassembling equipment. Untrained personnel shall not disassemble Harmonic products. Unfamiliarity with tools can cause damage and injury. Règles de sécurité (French) Le personnel du recycleur doit porter de l'équipement de protection individuelle, y compris des...
Page 348 Information Le personnel du recycleur doit avoir de l'expérience des outils de démontage de l'appareil. Les produits Harmonic ne doivent pas être démontés par du personnel non qualifié. Une mauvaise connaissance des outils peut causer des dommages et des blessures.
Page 349 If this was sold or purchased by mistake, it should be replaced with a residential-use type. g. Class A Statement (China) English translation of the notice above: © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release Release 4.1, Rev A...
Page 350: Product Regulatory Compliance Markings
Product Regulatory Compliance Please visit Harmonic page to view information on applied safety & EMC standards and regulatory marks on Harmonic products. You can also email us at regulatory.compliance@harmonicinc.com for assistance on regulatory compliance for Harmonic products.
Page 351 Warning Japan VCCI V-3/201 5.04; VCCI CISPR 22:2008, Class Australia AS/NZS Safety C-Tick and New CISPR22:2009+A1:2 Zealand 010; Class A Korea KN32 Class A and KN © 2017 Harmonic Inc. All rights reserved. Harmonic MediaGrid Release Release 4.1, Rev A...
Page 352 Product Environmental Compliance Harmonic manufactures high quality and innovative IT and telecommunications equipment, video delivery infrastructure solutions and services for its customers worldwide. Harmonic is committed to providing our customers with safe and environmentally friendly products that are compliant with all relevant regulations, customer specifications, and environmental legislation, including the directives described below.
Page 353: China Rohs
European Union’s regulation on chemicals and their safe use which came into force in June, 2007. Harmonic supports the basic aim of REACH in improving the protection of human health and environment through the better and earlier identification of intrinsic properties of chemical substances.
Page 354 Appendix B Safety and Regulatory Compliance Product Environmental Compliance Information China RoHS Disclosure Report Below table shows the presence of hazardous substances, or elements in Harmonic products, if the part is present. 该表显示哈雷公司产品中可能含有的有毒有害物质元配件的信息，除了来源于元配件供应商的物料成分资料，亦来自其它相关的机构与资料。哈雷产品不一定使用这些元配件。 This table shows those components where hazardous substances may be found in Harmonic...
Page 355 Note 3: The “–” indicates that the restricted substance corresponds to the exemption. Other RoHS and REACH type Regulations Harmonic will comply with RoHS and REACH type regulations evolving in other countries, if they become relevant to our products or in markets where we sell our products.
Page 356 In order to assist EU member states to preserve, protect and improve the quality of the environment, protect human health and utilize natural resources prudently and rationally, Harmonic strives to recycle in compliance with the WEEE Directive any of its products that cannot be re-used.
Page 357 Compliance with additional country specific environmental, safety, and EMC standards Information Harmonic will pay for the cost of shipping and will provide a Certificate of Recycling or a Certificate of Destruction upon request. For more information on collection, reuse and recycling or to initiate the WEEE take-back process, please complete the form at http:// www.harmonicinc.com/webform/weee-takeback-request or contact...

Harmonic MediaGrid Installation And Configuration Manual

Introduction

Chapter 1: System Overview and Requirements

Chapter 2: System Installation with the Contentserver 4000 Series

Chapter 3: System Installation with the Contentserver 3000 Series

Chapter 4: System Configuration

Chapter 5: Installing the File System Driver

Chapter 6: Accessing the Harmonic Mediagrid

Chapter 7: Administrative Procedures

Chapter 8: Hardware Reference

Chapter 9: Troubleshooting

Appendix A: Legacy Hardware Platforms

Quick Links

Troubleshooting

Need help?

Questions and answers

Related Manuals for Harmonic MediaGrid

Summary of Contents for Harmonic MediaGrid
