  • Page 1 Spectrum ™ MediaCenter Component Replacement Guide Revision C...
  • Page 2 Harmonic assumes no responsibility or liability arising from the use of the products described herein, except as expressly agreed to in writing by Harmonic. The use and purchase of this product do not convey a license under any patent rights, copyrights, trademark rights, or any intellectual property rights of Harmonic.
  • Page 3 Agreement, installing or downloading the Software as defined below or using the Software preloaded or embedded in your System. As used herein, the term "Software" means the Harmonic owned software and/or firmware used in or with the Products and embedded into, provided with or loaded onto the Products in object code format, but does not include, and this Agreement does not address, any third-party or free or open source software separately licensed to you ("Third Party Software").
  • Page 4 U.S. Government as end users (a) only as Commercial Items and (b) with only those rights as are granted to all other end users pursuant to the terms and conditions herein. Harmonic, 4300 North First Street, San Jose, CA 95134, U.S.A.
  • Page 5 Copyright © 2015–2016 Harmonic Inc. All rights reserved. Harmonic, the Harmonic logo, Omneon, the Omneon logo, [all other Harmonic products mentioned] are trademarks, registered trademarks or service marks of Harmonic Inc. in the United States and other countries. Dolby, Dolby Digital, Dolby Digital Plus and Dolby E are registered trademarks of Dolby Laboratories.

  • Page 6: Table Of Contents

    Table of Contents Chapter 1: Introduction ........................6 Chapter 2: MediaCenter 2200B component replacement ............7 Bezel replacement..........................7 Removing the bezel........................7 Installing the bezel........................8 Drive replacement..........................9 About replacement drives......................9 Drive numbering........................10 Failing a drive........................... 10 Verifying which drive to remove....................10 Removing a failed drive......................
  • Page 7 Moving players from one Spectrum server to another................. 59 Removing a MediaCenter from SystemManager................. 60 Configuring the MediaCenter......................60 Verifying functionality........................61 Appendix A: Harmonic Technical Assistance Center contact information ........ 62 Harmonic corporate contact information.................... 63 Appendix B: Safety and regulatory compliance information .............
  • Page 8 Table of Contents China RoHS..........................82 Other RoHS and REACH type regulations..................84 Waste Electrical and Electronic Equipment (WEEE)............... 84 Battery directive......................... 84 WEEE Take-Back Request Program....................84 Compliance with additional country specific environmental, safety and EMC standards:......85 MediaCenter Component Replacement Guide...

  • Page 9: Chapter 1: Introduction

    This guide provides information to help you replace components in your Spectrum device or system. Make sure that you read all safety warnings and instructions, and that you have received a replacement component from Harmonic before you begin any of the procedures in this guide.

  • Page 10: Chapter 2: Mediacenter 2200B Component Replacement

    Boot drive replacement Bezel replacement Over time, the bezel LEDs can wear out. Replacement bezels are available from Harmonic. CAUTION: The front panel is susceptible to electrostatic discharge (ESD) when the bezel is removed. Wear the appropriate ESD protection when you remove the bezel.

  • Page 11: Installing The Bezel

    Fastener Installing the bezel Align the bezel in front of the chassis so that the Harmonic logo appears on the top left corner. 1. Keeping the corners aligned, press the bezel straight onto the chassis. NOTE: Ensure that the bezel is aligned correctly on the chassis. When the bezel sits correctly, the front panel LEDs will return to their previous state after about 30 seconds.

  • Page 12: Drive Replacement

    Harmonic. IMPORTANT: Use ONLY Harmonic-supplied replacement disk drives. Disk drives from any other source will be excluded from coverage under the Harmonic product limited warranty and maintenance services programs. In addition, any errors or damages caused by the use of disk drives provided from any other source will cause the entire product to be excluded from coverage under the Harmonic product limited warranty and maintenance services programs.

  • Page 13: Drive Numbering

    If you wish to install a Harmonic-supplied drive model that is not supported by your current version of Spectrum firmware, you may need to install a “DDC” configuration file to your video server, which enables you to install and use the new drive. For details, see “Installing a DDC file” in the Harmonic SystemManager User Guide.

  • Page 14: Removing A Failed Drive

    4. If you identify the correct drive, remove the drive according to the instructions in "Removing a failed drive". CAUTION: Wait 30 seconds before unlatching the drive. 5. If you do not identify the correct drive, call Harmonic Technical Support and do not continue with this procedure. Removing a failed drive It is critical that you identify the correct drive.

  • Page 15: Installing A Replacement Drive

    • If the serial numbers do not match, wait at least 15 seconds after removal, then reinsert the drive. Call Harmonic Technical Support immediately, and do not continue with this procedure. Installing a replacement drive Verify that the new drive is reported as Alive and monitor the progress of the RAID rebuild after installing NOTE: When installing a drive, ensure that the adjacent drive is fully installed.
  • Page 16 Once complete, the RAID status changes to Normal, Attached, Viable. What to do next If you replaced a failed drive with a new drive from Harmonic, use the packaging materials (carton, cushion, and electrostatic sensitive bag) from the replacement disk drive to carefully repackage the failed...

  • Page 17: Fan Replacement

    A non-skid surface may be needed to prevent the server system from sliding on your work surface. Before you begin Unpack the replacement component and visually inspect for any damage. If it is damaged, call Harmonic Technical Support and do not continue with this procedure.
  • Page 18 MediaCenter 2200B component replacement 3. Slide the cover back and lift upward. MediaCenter Component Replacement Guide...

  • Page 19: Fan Numbering

    Spectrum Fan numbering Fans are numbered from left to right when looking at the front panel. Be sure to correctly identify the failed fan before removing it from the chassis.

  • Page 20: Replacing A Fan

    MediaCenter 2200B component replacement Replacing a fan Each fan is designed for tool-less removal and insertion. 1. Squeeze the two loop handles on the top side of the fan, and pull straight up until it clears the fan assembly bracket. 2.

  • Page 21: Installing The System Cover

    Spectrum Installing the system cover The server system must be operated with the system cover in place to ensure proper cooling. 1. Place the system cover onto the chassis and slide forward until the front edge of the system cover is pressed up against the back edge of the front drive bay.

  • Page 22: Removing The System Cover

    A non-skid surface may be needed to prevent the server system from sliding on your work surface. Before you begin Unpack the replacement component and visually inspect for any damage. If it is damaged, call Harmonic Technical Support and do not continue with this procedure.
  • Page 23 Spectrum 1. Remove PCI Riser 1 assembly as follows: a. From the outside of the chassis, press the riser assembly faceplate in and upward until the riser becomes dislodged. b. Gently push the tab on the plastic air duct away from the riser assembly, just until you can freely lift the riser assembly.
  • Page 24 MediaCenter 2200B component replacement 3. Slide the card out of the riser bracket. 4. Insert the replacement card in the same PCI slot from you which you removed the failed card, ensuring that the edge connector is fully seated inside the PCI slot on the riser card. Warning: Each PCI add-in card is designed to work in a specific PCI slot.
  • Page 25 Spectrum 5. Secure the card to the riser bracket with the fastener screw. Edge Connector 6. Install PCI Riser 1 assembly as follows: a. Grasp the riser assembly with both hands and lower the front end of the riser assembly first, aligning the riser edge connector with the corresponding riser slot on the server board.

  • Page 26: Replacing The Ethernet Card In Pci Riser 2

    MediaCenter 2200B component replacement b. Lower the back end of the riser assembly, lining up the tabs on riser assembly with the holes on the back panel of the chassis. Riser edge connector Riser slot c. Press down on the riser assembly bracket and faceplate until firmly seated. CAUTION: Do not rock the riser assembly into place.
  • Page 27 Spectrum b. Grasp PCI Riser 2-3 assembly with both hands and pull the riser assembly out of the riser slot, being careful to clear the LTC connector away from the rear panel before lifting up. 2. Remove the fastener screw that secures the card to the riser bracket.
  • Page 28 MediaCenter 2200B component replacement 3. Slide the card out of the riser bracket. 4. Insert the replacement card in the same PCI slot from you which you removed the failed card, ensuring that the edge connector is fully seated inside the PCI slot on the riser card. Warning: Each PCI add-in card is designed to work in a specific PCI slot.
  • Page 29 Spectrum 5. Secure the card to the riser bracket with the fastener screw. Edge Connector 6. Install PCI Riser 2-3 assembly as follows: a. Grasping the riser assembly with both hands, lower the back end of the riser assembly first, clearing the LTC connector from the rear panel as you position the riser assembly over the riser slot.

  • Page 30: Replacing The Ethernet Card In Pci Riser 3

    MediaCenter 2200B component replacement NOTE: The add-in cards installed in PCI Riser 3 may obstruct your view, making it difficult to align its edge connector with the corresponding riser slot. c. Press gently on the back of the riser assembly first, then the front, until both edge connectors are firmly seated in their riser slots.
  • Page 31 Spectrum b. Grasp PCI Riser 2-3 assembly with both hands and pull the riser assembly out of the riser slot, being careful to clear the LTC connector away from the rear panel before lifting up. 2. Remove the fastener screw that secures the card to the riser bracket.
  • Page 32 MediaCenter 2200B component replacement 3. Slide the card out of the riser bracket. 4. Insert the replacement card in the same PCI slot from you which you removed the failed card, ensuring that the edge connector is fully seated inside the PCI slot on the riser card. Warning: Each PCI add-in card is designed to work in a specific PCI slot.

  • Page 33: Installing The System Cover

    Spectrum a. Grasping the riser assembly with both hands, lower the back end of the riser assembly first, clearing the LTC connector from the rear panel as you position the riser assembly over the riser slot. b. Align the front end of the edge connector on PCI Riser 2 with the corresponding riser slot on the server board.

  • Page 34: Optical 10Gbe Iom Replacement

    MediaCenter 2200B component replacement 3. Using a screwdriver, install the top cover screw(s). What to do next Follow instructions in the Spectrum System Installation Guide for reconnecting the MediaCenter to your Spectrum system and powering on the device. Optical 10GbE IOM replacement Follow this procedure to replace the dual-port optical 10 GbE I/O module while keeping the existing SFP transceivers.

  • Page 35: Removing The System Cover

    A non-skid surface may be needed to prevent the server system from sliding on your work surface. Before you begin Unpack the replacement component and visually inspect for any damage. If it is damaged, call Harmonic Technical Support and do not continue with this procedure.

  • Page 36: Replacing The Optical 10Gbe I/O Module

    MediaCenter 2200B component replacement 3. Slide the cover back and lift upward. Replacing the optical 10GbE I/O module You must remove PCI Riser 1 assembly before you can remove the I/O module, which lies on the bottom of the server board. 1.
  • Page 37 Spectrum c. Grasp the riser assembly with both hands and lift straight up. 2. Remove the failed I/O module as follows: a. Remove the three screws securing the I/O module to the chassis. Keep them in a safe place so that you may use them to install the new I/O module. b.

  • Page 38: Installing The System Cover

    MediaCenter 2200B component replacement a. Grasp the riser assembly with both hands and lower the front end of the riser assembly first, aligning the riser edge connector with the corresponding riser slot on the server board. b. Lower the back end of the riser assembly, lining up the tabs on riser assembly with the holes on the back panel of the chassis.

  • Page 39: Installing The Sfp Transceiver

    Spectrum 3. Using a screwdriver, install the top cover screw(s). What to do next Follow instructions in the Spectrum System Installation Guide for reconnecting the MediaCenter to your Spectrum system and powering on the device. Installing the SFP transceiver The SFP transceiver is designed to fit firmly in the SFP cage. A reasonable amount of friction is normal, especially with new I/O modules.

  • Page 40: Sfp Transceiver Replacement

    You will hear an audible click when the cable is secure. SFP transceiver replacement Use only Harmonic-supplied optical SFP transceivers in the dual-port optical 10 GbE IOM in the MediaCenter. DANGER: Observe all conventional ESD precautions when handling Spectrum devices and components.

  • Page 41: Installing The Sfp Transceiver

    Before you begin Unpack the replacement component and visually inspect for any damage. If it is damaged, call Harmonic Technical Support for assistance and do not continue with this procedure. 1. Detach the power cord from the power supply to be removed.

  • Page 42: Boot Drive Replacement

    MediaCenter 2200B component replacement After you remove the power supply, the power supply LED remains lit for a short period of time. 3. Insert the power supply module into the power supply bay. 4. Push the power supply module into the bay until it locks into place. Boot drive replacement The MediaCenter contains one 2.5"...

  • Page 43: About Replacement Drives

    If you wish to install a Harmonic-supplied drive model that is not supported by your current version of Spectrum firmware, you may need to install a “DDC” configuration file to your video server, which enables you to install and use the new drive. For details, see “Installing a DDC file” in the Harmonic SystemManager User Guide.

  • Page 44: Replacing The Boot Drive

    Before you begin Unpack the replacement component and visually inspect for any damage. If it is damaged, call Harmonic Technical Support for assistance and do not continue with this procedure. 1. Power down the MediaCenter. Follow instructions in "Powering down a Spectrum video server" in this guide.
  • Page 45 Spectrum 5. Insert the drive carrier into the bay, sliding the drive until it contacts the backplane. 6. Close the drive carrier release handle to lock the drive into place. 7. Power up the MediaCenter. Follow instructions in the Spectrum System Installation Guide. 8.

  • Page 46: Starting The File System

    MediaCenter 2200B component replacement A confirmation dialog appears. 5. Click OK. 6. Verify that the video server's status changes to Not Responding. Starting the file system Use this procedure to start an existing File System that has been previously initialized. The procedure is typically used after performing maintenance on the File System, or when starting a File System in configurations with more than one MediaDirector.

  • Page 47: Configuring The Mediacenter

    Filetypes.conf File” in the Harmonic SystemManager User Guide. 6. If you had previously configured audio profile groups, configure new audio profile groups to match your original settings. For instructions, refer to "Creating an audio profile group" in the Harmonic SystemManager User Guide.

  • Page 48: Chapter 3: Mediacenter 2200/2200A Component Replacement

    Power supply unit replacement Bezel replacement Over time, the bezel LEDs can wear out. Replacement bezels are available from Harmonic. CAUTION: The front panel is susceptible to electrostatic discharge (ESD) when the bezel is removed. Wear the appropriate ESD protection when you remove the bezel.

  • Page 49: Installing The Bezel

    Spectrum Installing the bezel Align the bezel in front of the chassis so that the Harmonic logo appears on the top left corner. 1. Attach the LED connector on the bezel to the LED connector on the chassis. 2. Gently press the bezel straight onto the chassis.

  • Page 50: Drive Replacement

    If you wish to install a Harmonic-supplied drive model that is not supported by your current version of Spectrum firmware, you may need to install a “DDC” configuration file to your video server, which enables you to install and use the new drive. For details, see “Installing a DDC file” in the Harmonic SystemManager User Guide.

  • Page 51: Failing A Drive

    4. If you identify the correct drive, continue with removing the drive. CAUTION: Wait 30 seconds before unlatching the drive. 5. If you do not identify the correct drive, call Harmonic Technical Support and do not continue with this procedure.

  • Page 52: Installing A Replacement Drive

    Before you begin Unpack the replacement component and visually inspect for any damage. If it is damaged, call Harmonic Technical Support for assistance and do not continue with this procedure. 1. Press the red release button on the right side of the drive to release the handle.

  • Page 53: Fan Replacement

    Once complete, the RAID status changes to Normal, Attached, Viable. What to do next If you replaced a failed drive with a new drive from Harmonic, use the packaging materials (carton, cushion, and electrostatic sensitive bag) from the replacement disk drive to carefully repackage the failed drive and return it promptly for analysis.

  • Page 54: Removing The Cover

    CAUTION: Power down the MediaCenter and unplug all peripheral devices. Before you begin Unpack the replacement component and visually inspect for any damage. If it is damaged, call Harmonic Technical Support for assistance and do not continue with this procedure.

  • Page 55: Installing The Cover

    Spectrum 2. Grasp the fan and firmly pull the fan from the unit. 3. Depress and hold down the release on each side of the replacement fan. 4. Push the fan firmly into the slot until you hear a click. Installing the cover The server system must be operated with the system cover in place to ensure proper cooling.

  • Page 56: Replacing A Power Supply Unit

    Before you begin Unpack the replacement component and visually inspect for any damage. If it is damaged, call Harmonic Technical Support for assistance and do not continue with this procedure. 1. Disconnect the AC power cable.
  • Page 57 Spectrum...

  • Page 58: Chapter 4: Mediacenter Chassis Replacement

    IMPORTANT: If you need to replace a Spectrum video server that is configured for Polaris Play: Playlist Control, contact Harmonic Technical Support for assistance with saving all necessary settings so they can be moved to the replacement video server. Failure to save...

  • Page 59: Replacing The Chassis

    Configure DDC File: If you have installed a DDC configuration file, you will need to reinstall the same file when configuring settings on the replacement MediaCenter. Refer to "Installing a DDC file" in the Harmonic SystemManager User Guide for information on viewing your DDC file configuration.

  • Page 60: Powering Down A Spectrum Video Server

    MediaCenter to use either DHCP or static IP addresses. After removing the original MediaCenter, you can configure the replacement to use the same IP addresses. If you do not have a DHCP server, contact Harmonic Technical Support for assistance.

  • Page 61: Starting The File System

    Spectrum Connecting these interfaces to your network before you configure them properly may result in network problems. 1. From the System Diagram page, click an individual host MediaCenter icon. The Physical Configuration page displays. 2. Click the MediaCenter icon. The Spectrum Server Properties page displays. 3.

  • Page 62: Moving Players From One Spectrum Server To Another

    The selected players will disappear from the list. 7. Click Done to complete the move. 8. Harmonic recommends you verify that the players are usable by recording or playing material using those players on their new Spectrum server. MediaCenter Component Replacement Guide...

  • Page 63: Removing A Mediacenter From Systemmanager

    Failover settings. 2. Configure your Harmonic MediaGrid accounts. Refer to “Connecting to a Harmonic MediaGrid from the Spectrum video server” in the Harmonic SystemManager User Guide for information on configuring your Harmonic MediaGrid Accounts. 3. Configure your Access Control settings. Refer to “Configuring Access Control settings for video servers”...

  • Page 64: Verifying Functionality

    Filetypes.conf File” in the Harmonic SystemManager User Guide. 6. If you had previously configured audio profile groups, configure new audio profile groups to match your original settings. For instructions, refer to "Creating an audio profile group" in the Harmonic SystemManager User Guide.

  • Page 65: Appendix A: Harmonic Technical Assistance Center Contact Information

    Appendix A Harmonic Technical Assistance Center contact information A list of phone numbers, e-mail addresses, and important links for the Harmonic Technical Assistance Center (TAC). Table A-1: Technical Assistance Center phone numbers and email addresses Region Telephone Technical Email Support Americas 888.673.4896...

  • Page 66: Harmonic Corporate Contact Information

    Harmonic Technical Assistance Center contact information Harmonic corporate contact information Phone numbers and addresses for the corporate office. Harmonic corporate address 4300 North First Street San Jose, CA 95134 U.S.A. Harmonic corporate telephone numbers Tel. 1.800.788.1330 (from the U.S. and Canada) Tel.

  • Page 67: Appendix B: Safety And Regulatory Compliance Information

    Legal disclaimer: Information in this document is provided in connection with Harmonic products. Unless otherwise agreed in writing Harmonic products are not designed nor intended for any application in which the failure of the product could cause personal injury or death.

  • Page 68: Safety Symbols & Translated Safety, Warning & Caution Instructions (English)

    To avoid personal injury or property damage, before you begin installing or replacing the product, read, observe, and adhere to all the following safety instructions and information. Harmonic products and/or product packaging may be marked with the safety symbols used throughout this document, when it is necessary to alert operators, users, and service providers to pertinent safety instructions in the manuals.
  • Page 69 Spectrum Mark Notes Chassis warning • Before connecting or disconnecting ground or power wires to the chassis, ensure that power is removed from the DC circuit. • To prevent personal injury or damage to the chassis, lift the unit only by using handles that are an integral part of the chassis, or by holding the chassis underneath its lower edge.

  • Page 70: Symboles De Sécurité Et Traduits De Sécurité, D'avertissement Et Attention Instructions (Français)

    • Dispose of used batteries according to the manufacturer's instructions • There are no user-serviceable batteries inside Harmonic products. Refer to Harmonic qualified personnel only to service the replaceable batteries Caution Symboles de sécurité et traduits de sécurité, d'avertissement et Attention Instructions (français)
  • Page 71 Spectrum de sécurité utilisés dans le présent document, lorsque cela est nécessaire pour alerter les opérateurs, les utilisateurs et les fournisseurs de services de consignes de sécurité pertinentes dans les manuels. Mark Notes Installation ou remplacement de l'unité de produit avertissement •...
  • Page 72 Safety and regulatory compliance information Mark Notes Choc électrique avertissement • Il est possible que cette unité soit munie de plusieurs cordons d'alimentation. Pour éviter les risques d'électrocution, débrancher les deux cordons d'alimentation avant de réparer l'unité. • Avant de travailler sur un châssis ou à proximité d'une alimentation électrique, débrancher le cordon d'alimentation des unités en courant Avertissement alternatif.

  • Page 73: Sicherheit Symbole Und Übersetzt Sicherheit, Achtung & Vorsicht Anleitung (Deutsch)

    • Mettre au rebut les batteries usagees conformement aux instructions du fabricant. • Les batteries des produits Harmonic ne peuvent pas être réparées ni entretenues par l'utilisateur. Ne confier l'entretien des batteries remplaçables Attention qu'à du personnel compétent de Harmonic.
  • Page 74 Safety and regulatory compliance information Informationen. Harmonic Produkte und / oder Produktverpackungen können mit den Sicherheitssymbole in diesem Dokument verwendet werden, markiert, wenn es notwendig ist für die Betreiber, Anwender und Dienstleister, um relevante Sicherheitsanweisungen in den Handbüchern zu alarmieren.
  • Page 75 Spectrum Mark Notes Chassis Warnung • Gleichstrom-Unterbrechung Bevor Sie Erdungs- oder Stromkabel an das Chassis anschließen oder von ihm abtrennen, ist sicherzustellen, daß der Gleichstrom-Stromkreis unterbrochen ist. • Um Verletzungen und Beschädigung des Chassis zu vermeiden, sollten Sie das Chassis nicht an den Henkeln auf den Elementen (wie z.B. Warnung Stromanschlüsse, Kühlungen oder Karten) heben oder kippen;...
  • Page 76 Safety and regulatory compliance information Mark Notes Elektroschock-Warnung • Diese Einheit hat möglicherweise mehr als ein Netzkabel. Zur Verringerung der Stromschlaggefahr trennen Sie beide Netzgerätekabel ab, bevor Sie die Einheit warten. • Vor der Arbeit an einem Chassis für Arbeiten in der Nähe Stromversorgung, ziehen Sie das Netzkabel mit Netzeinheiten.
  • Page 77 Warnung • Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr • Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. • Es gibt keine zu wartenden Akkus im Harmonic Produkte. Siehe Harmonic qualifiziertes Personal, um die austauschbare Batterien Service Vorsich...

  • Page 78: Site Preparation Instructions

    Do not move or ship equipment unless it is correctly packed in its original wrapping and shipping containers. ◦ Only allow Harmonic trained personnel to undertake equipment service and maintenance. Do not permit unqualified personnel to operate the unit. ◦...

  • Page 79: Product End-Of-Life Disassembly Instructions

    Product end-of-life disassembly instructions For disassembly instructions, please call the technical support in order to remove components requiring selective treatment, as defined by the EU WEEE Directive (2012/19/EU). See Harmonic Technical Assistance Center contact information on page 62. 1. Disassemble equipment at a dedicated area only, gather the needed tools for disassembly.

  • Page 80: Safety Rules (English)

    Le personnel du recycleur doit avoir de l'expérience des outils de démontage de l'appareil. Les produits Harmonic ne doivent pas être démontés par du personnel non qualifié. Une mauvaise connaissance des outils peut causer des dommages et des blessures.
  • Page 81 FCC radio frequency emission limits. Modifications to this equipment not expressly approved by Harmonic may void the authority granted to the user by the FCC to operate this equipment and you may be required to correct any interference to radio or television communications at your own expense.

  • Page 82: Product Regulatory Compliance Markings

    Safety and regulatory compliance information English translation of the notice above: This is a Class A device and is registered for EMC requirements for industrial use. The seller or buyer should be aware of this. If this was sold or purchased by mistake, it should be replaced with a residential-use type.
  • Page 83 Spectrum Country/ Testing Certification Regulatory Product marks region standard/ type mark name specification USA/ FCC CFR 47 Canada Class A Part 15, Class Statement ICES-003: Issue 5, 2012; Class A European Safety and CE / Low RoHS: EN Union Voltage 50581:2012;...

  • Page 84: Product Environmental Compliance

    Harmonic manufactures high quality and innovative IT and telecommunications equipment, video delivery infrastructure solutions and services for its customers worldwide. Harmonic is committed to providing our customers with safe and environmentally friendly products that are compliant with all relevant regulations, customer specifications, and environmental legislation, including the directives described below.

  • Page 85: Eu Reach

    European Union’s regulation on chemicals and their safe use which came into force in June, 2007. Harmonic supports the basic aim of REACH in improving the protection of human health and environment through the better and earlier identification of intrinsic properties of chemical substances. Harmonic products are considered “articles”...
  • Page 86 Safety and regulatory compliance information China RoHS Disclosure report Below table shows the presence of hazardous substances, or elements in Harmonic products, if the part is present. 该表显示哈雷公司产品中可能含有的有毒有害物质元配件的信息，除了来源于元配件供应商的物料成分资 料， 亦来自其它相关的机构与资料。哈雷产品不一定使用这些元配件。 This table shows those components where hazardous substances may be found in Harmonic products based on, among other things, material content information provided by third party suppliers.

  • Page 87: Other Rohs And Reach Type Regulations

    SJ/T11363 2006 standard. Other RoHS and REACH type regulations Harmonic will comply with RoHS and REACH type regulations evolving in other countries, if they become relevant to our products or in markets where we sell our products.

  • Page 88: Compliance With Additional Country Specific Environmental, Safety And Emc Standards

    Harmonic’s WEEE Take-Back program for product disposal. Harmonic will pay for the cost of shipping and will provide a Certificate of Recycling or a Certificate of Destruction upon request. For more information on collection, reuse and recycling or to initiate the WEEE take-back process, please complete the form at http://www.harmonicinc.com/webform/weee-...
  • Page 89 Copyright © 2016 Harmonic Inc. All rights reserved.
