Harmonic MediaGrid ContentStore 5840A Quick Reference Manual

Harmonic MediaGrid ContentStore 5840A
Front Panel Components and Drive Location
5
3 4
1
2
1 Operator's panel
2 Drawer 2
Rear Panel Components
1
1 I/O Module
2 I/O Module Power and Fault LEDs
3 For factory use only
4 12Gb SAS Connectors
Harmonic Technical Support: +1 888 673 4896 (Americas), +65 6542 0050 (Asia Pacific), + 44 1252 555 450 (EMEA),
+7 495 506-5981 (Russia, CIS), +81 3 5565 6737 (Japan), +86 10 8391 3313 (China, mainland)
Quick Reference Guide
6
3 Drawer LEDs 5 Anti-tamper lock
4 Drawer Latch 6 Drawer 1
2 3 4 5
С
9
5 External Host Port Activity LEDs
6 Cooling Module Release Latch
7 Cooling Module
8 Cooling Module LEDs
Drawer 1 (Top)
28 41
27
14
0 13
The above diagrams show drive numbering as viewed
when looking down on open drawers.
10 11
9 Power Supply Unit (PSU)
10 PSU Release Latch
11 PSU LEDs
12 PSU Power Switch
Drawer 2 (Bottom)
70 83
56 69
42 55
С
6
7
8
12
006-0240-001 Rev. A
